10 Technical data
Description Data
Mains voltage [V] 230/400 AC (Europe)
Rated current [A] 16 or 32 (single phase or 3-phase)
Grid frequency [Hz] 50
Network types TT / TN
EMC class Emitted interference: class B (residential, business, commercial areas)
Immunity: industrial areas
Overvoltage category III as per EN 60664
Protection class I
IP-protection class IP54
Protection against mechanical im-
pact
IK08
Protective devices A residual current circuit breaker and line circuit breaker must be provided on the installation
side. See Installation and electrical connection.
Fixation type Wall and base mounting (permanently connected)
Cable feed Mounted on-wall or in-wall
Power supply conductor cross sec-
tion
Depending on the cable and type of installation, the minimum cable cross-section for a stand-
ard installation is:
6 mm² (for 16 A)
10 mm² (for 32 A)
Charging cable with charging
coupling
Type 2 according to EN 62196-1 and EN62196-2
Mains connection terminal Connection cable:
n rigid (min.-max.) 2.5-10mm²
n flexible (min.-max.) 2.5-10mm²
n flexible (min.-max.) with wire end ferrule 2.5-10mm²
Output voltage [V] 230/400 AC
Max. charging power [kW] 11 kW or 22 kW (depending on factory configuration)
Operating temperature range [°C] -25 to +55 (without direct solar radiation)
Storage temperature range [°C] -25 to +80
Display LED element
Lock Key-operated switch set to start charging
Altitude [m] max. 2000 (above sea level)
Permissible relative humidity [%] 5 up to 95 Non-condensing
Weight [kg] 11 kW: 4.6
22 kW: 5.6
Dimensions [mm] See figures in Assembly

Webasto Pure Specifications

General

Connector Type	Type 2
Protection Class	IP54
Charging Current	32 A
Input Voltage	400 V AC
Output Voltage	400 V AC
Output Current	32 A
Power	22 kW
Protection Features	Overcurrent, Overvoltage, Short Circuit, Overheating
Charging Power	22 kW
Phases	1-phase or 3-phase (depending on model)
