15. To reinstall the manifold assembly, reverse steps 7 through 14.
CAUTION: The burner openings (1) must be positioned
properly over the valve orifi ces (2).
Check proper assembly before fastening manifold in place.
(2)
(1)
WARNING: After reinstalling the gas lines, they should
be leak checked with a soap and water solution before
using the grill. (See, “Check for gas leaks.”)
(1)
(2)
CROSSOVER
®
IGNITION SYSTEM OPERATIONS
If the Crossover ignition system fails to ignite the LEFT burner in a burner set,
light the LEFT burner with a match. If the LEFT burner lights with a match,
then check the Crossover
®
ignition system.
• Check that both ignition wires(1,2) are attached properly.
• Check that the Crossover
®
ignition button is activating.
• You should hear the igniter sparking.
If the Crossover
®
ignition system still fails to light, contact the Customer
Service Representative in your region using the contact information sheet
provided with your manual.
MAINTENANCE
REPLACE IGNITER BATTERIES
Parts required: 1 AA alkaline battery per igniter.
Unscrew igniter button from top of control panel. Remove igniter button and
contact spring. Remove old battery and replace with a new AA alkaline battery.
Positive end(1) of battery faces up as shown in illustration. Replace spring
contact(2) and screw igniter button(3) back down.
