Weber Baby Q User Manual

2
Lid - 1
1 -
2 -
2 -
2 -
2 -
1 -
Handle - 1
Stainless Steel Pan Head
Phillips Screw
(1/4 - 20 x 1 1/2 inch Screw) - 2
Handle Spacer - 2
Cotter Pin - 2
Disposable Drip Pan - 2
Control knob - 1
A
1
2
B
Catch Pan - 1
Cooking Grate - 1
Hinge Pin - 2
PARTS LIST
ASSEMBLYd - 1
Height Lid Close
Gas Connection Right
Hand Side of Barbecue
35.56 (cm)
22.56 (cm)
base to
cooking surface
The minimum cylinder capacity for this barbecue is 4.5 kg
The maximum cylinder capacity for this barbecue is 9 kg

Weber Baby Q Specifications

General

Type	Portable Gas Grill
Main Burners	1
Total Cooking Area	189 square inches
BTU-per-hour Input	8, 500
Ignition System	Push-button ignition
Grate Material	Porcelain-enameled cast iron
Fuel Type	Liquid Propane
Model	Q 1000
Material	Cast aluminum
Warranty	5 years
