B-3
Insert casters
You will need: frame assembly and two casters.
Push the casters firmly into the inserts in the ends of
the caster frame.
(1)
(2)
Add cooking box (assembly)
You will need: frame assembly, cooking box (assem-
bly), 2 inch bolt, nylon washer, keps nut, pliers and a 7/
16 inch or adjustable wrench.
Place the cooking box (assembly) in the frame assem-
bly so the burner tubes(1) are under the frame
brace(2).
Slide the cooking box (assembly) to the left within the
frame assembly. Add the nylon washer to the bolt.
Insert the bolt through the cooking box and frame with
the head of the bolt outside the box. Add the keps nut.
Tighten by holding the bolt with pliers while you tighten
the nut with a wrench.
