Genesis® II LX Burner Valve Orifice Sizes & Consumption Data
BURNER VALVE ORIFICE SIZES
Country Gas Category 2 Burner Models 3 Burner Models 4 Burner Models 6 Burner Models
China, Cyprus,
CzechRepublic, Denmark,
Estonia, Finland, HongKong,
Hungary, Iceland, India,
Israel, Japan, Korea,
Latvia, Lithuania, Malta,
Netherlands, Norway,
Romania, Russia, Singapore,
SlovakRepublic, Slovenia,
South Africa, Sweden,
Turkey
I
3B/P
(30 mbar or 2.8 kPa) Main Burners 1,06 mm
Side Burner 1,02 mm
Main Burners 1,06 mm
Side Burner 1,02 mm
Main Burners 1,03 mm
Side Burner 1,02 mm
Main Burners 0,98 mm
Side Burner 1,02 mm
Belgium, France,
Greece, Ireland, Italy,
Luxembourg, Portugal,
Spain, Switzerland,
UnitedKingdom
I
3+
(28-30/37 mbar) Main Burners 0,98 mm
Side Burner 0,96 mm
Main Burners 1,02 mm
Side Burner 0,96 mm
Main Burners 0,96 mm
Side Burner 0,96 mm
Main Burners 0,92 mm
Side Burner 0,96 mm
Poland I
3P
(37 mbar) Main Burners 0,98 mm
Side Burner 0,96 mm
Main Burners 1,02 mm
Side Burner 0,96 mm
Main Burners 0,96 mm
Side Burner 0,96 mm
Main Burners 0,92 mm
Side Burner 0,96 mm
Austria, Germany I
3B/P
(50 mbar) Main Burners 0,93 mm
Side Burner 0,85 mm
Main Burners 0,94 mm
Side Burner 0,85 mm
Main Burners 0,86 mm
Side Burner 0,85 mm
Main Burners 0,84 mm
Side Burner 0,85 mm
CONSUMPTION DATA
2 Burner Models 3 Burner Models 4 Burner Models 6 Burner Models
12,0 kW Propane
13,8 kW Butane
858 g/h Propane
1004 g/h Butane
16,3 kW Propane
18,7 kW Butane
1165 g/h Propane
1361 g/h Butane
18,7 kW Propane
21,5 kW Butane
1337 g/h Propane
1565 g/h Butane
24,6 kW Propane
28,3 kW Butane
1758 g/h Propane
2059 g/h Butane

Weber GENESIS II LX Specifications

General

Stainless Steel Burners	Yes
Porcelain-enameled, Cast-iron Cooking Grates	Yes
Flavorizer Bars	Stainless Steel
Ignition	Electronic
Main Burners	3
BTU-per-hour Input	39, 000 BTU
Sear Station Burner BTU	9, 000 BTU
Thermometer	Yes
iGrill Compatibility	Yes
Side Tables	Yes
Warranty	10 years
