Webster JBE Series - Burner Model Configuration; Model Designation Breakdown

BURNER SERIES
JBE No FGR
JBEX With FGR
HOUSING SIZE
5, 7, 9
FUELS
G Gas
O Oil
C Gas / Oil
BLOWER MOTOR HP
50 5 HP
75 7.5 HP
100 10 HP
150 15 HP
200 20 HP
250 25 HP
300 30 HP
400 40 HP
500 50 HP
600 60 HP
750 75 HP
HEAD SIZE
J 12”
K 14”
L 16”
M 18”
N 20”
P 23”
MODEL JBE(X) BURNER MODEL CONFIGURATION
FIGURE A-2
JBEX5G - 75 K - RM7800L - M.25 - M - MA - UL/CSD-1
CODES AND
LISTINGS
UL
ULc
CSD-1
FM
IRI
NFPA-85
OIL SYSTEMS
Pressure Atomizing
MR Modulation By-Pass
Air or Steam Atomization
MA Air Atomization
MS Steam atomizing
GAS TRAIN VENDOR
VGD Siemens
VGG Siemens
M Maxon
Blank
All Others
(ASCO) - (std)
GAS TRAIN SIZE
.15 1 1/2 inches
.20 2 inches
.25 2 1/2 inches
.30 3 inches
.40 4 inches
GAS SYSTEMS
M Modulation
The above represents the common model designations.
Contact the factory for other options and special applications.
Page 5 Section A - GeneralJBE(X) Manual
FLAME SAFEGUARD VENDOR
DESIGNATION
RM7800L Honeywell
M Mark Autoame -mini mark
E110/EP170 Fireye
Nexus - N Fireye
LMV51 Siemens
LMV52 Siemens
LMV3 Siemens
