- 6 -
Motor Rating 60°C Insulation - AWG Copper Wire Size MCM Copper Wire Size
Volts HP 14 12 10 8 6 4 3 2 1 0 00 000 0000 250 300 350 400 500
1/2 710 1140 1800 2840 4420
3/4 510 810 1280 2030 3160
1 430 690 1080 1710 2670 4140 5140
200 1 1/2 310 500 790 1260 1960 3050 3780
2 240 390 610 970 1520 2360 2940 3610 4430 5420
3 180 290 470 740 1160 1810 2250 2760 3390 4130
5 0 170 280 440 690 1080 1350 1660 2040 2490 3050 3670 4440 5030
7 1/2 0 0 200 310 490 770 960 1180 1450 1770 2170 2600 3150 3560
1/2 930 1490 2350 3700 5760 8910
3/4 670 1080 1700 2580 4190 6490 8060 9860
1 560 910 1430 2260 3520 5460 6780 8290
230 1 1/2 420 670 1060 1670 2610 4050 5030 6160 7530 9170
2 320 510 810 1280 2010 3130 3890 4770 5860 7170 8780
3 240 390 620 990 1540 2400 2980 3660 4480 5470 6690 8020 9680
5 0 230 370 590 920 1430 1790 2190 2690 3290 4030 4850 5870 6650 7560 8460 9220
7 1/2 0 0 260 420 650 1020 1270 1560 1920 2340 2870 3440 4160 4710 5340 5970 6500 7510
1/2 3770 6020 9460
3/4 2730 4350 6850
1 2300 3670 5770 9070
1 1/2 1700 2710 4270 6730
460 2 1300 2070 3270 5150 8050
3 1000 1600 2520 3970 6200
5 590 950 1500 2360 3700 5750
7 1/2 420 680 1070 1690 2640 4100 5100 6260 7680
10 310 500 790 1250 1960 3050 3800 4680 5750 7050
Single Phase Motors
Two or Three Wire Cable, 60HZ (Service Entrance to Motor-Maximum Cable Length In Feet)
Three Phase Motors
Three Phase, Three Wire Cable, 60HZ (Service Entrance to Motor-Maximum Cable Length In Feet)
Table 2
Table 3
Motor Rating 60°C Insulation - AWG Copper Wire Size
Volts HP 14 12 10 8 6 4 3 2 1 0 00 000 0000
115 1/2 100 160 250 390 620 960 1190 1460 1780 2160 2630 3140 3770
1/2 400 650 1020 1610 2510 3880 4810 5880 7170 8720
3/4 300 480 760 1200 1870 2890 3580 4370 5330 6470 7870
1 250 400 630 990 1540 2380 2960 3610 4410 5360 6520
230 1 1/2 190 310 480 770 1200 1870 2320 2850 3500 4280 5240
2 150 250 390 620 970 1530 1910 2360 2930 3620 4480
3 0 190 300 470 750 1190 1490 1850 2320 2890 3610
5 0 0 0 280 450 710 890 1110 1390 1740 2170 2680
7 1/2 0 0 0 0 310 490 610 750 930 1140 1410 1720
60°C Insulation: The maximum temperature rating of the cable insulation. This includes the water temperature and the
increase in the insulation temperature caused by the current flowing thru the wire.
244504 1/2 115 60 1.60 10.0 670 12.0 960 1.0-1.3 64.4 R 35 20 30
Two 244505 1/2 230 60 1.60 5.0 670 6.0 960 4.2-5.2 32.2 R 20 10 15
Wire 244507 3/4 230 60 1.50 6.8 940 8.0 1310 3.0-3.6 40.7 N 25 15 20
244508 1 230 60 1.40 8.2 1210 9.8 1600 2.2-2.7 48.7 N 30 20 25
244309 1 1/2 230 60 1.30 10.6 1700 13.1 2180 1.5-1.9 66.6 M 35 20 30
Franklin Single Phase Motors
Single Phase Motor Specifications (60HZ) 3450 RPM
Table 4
Type Motor HP Volts HZ S.F.
Model (2) (2) Res.
Amps Watts Amps Watts M=Main Amps Code
S=Start
Std.
Fuse
Amps
Dual
Element
Time
Delay
Std.
Fuse
Amps
Circuit
Breaker
Or Fuse
Amps
Max Per
NEC
Rated Input
(Full Load)
Maximum
(S.F. Load)
Winding (1)
(Resistance
/Ohms)
Locked
Rotor
KVA
