- 7 -
214504 1/2 115 60 1.60 Y10.0 670 Y12.0 960 M1.0-1.3 50.5 M 35 20 30
B10.0 B12.0 S4.1-5.1
R0 R0
214505 1/2 230 60 1.60 Y5.0 670 Y6.0 960 M4.2-5.2 23.0 M 20 10 15
B5.0 B6.0 S16.7-20.5
Three R0 R0
Wire 214507 3/4 230 60 1.50 Y6.8 940 Y8.0 1310 M3.0-3.6 34.2 M 25 15 20
B6.8 B8.0 S10.7-13.1
R0 R0
214508 1 230 60 1.40 Y8.2 1210 Y9.8 1600 M2.2-2.7 41.8 L 30 20 25
B8.2 B9.8 S9.9-12.1
R0 R0
224300 1 1/2 230 60 1.30 Y10.0 1660 Y11.5 2100 M1.7-2.2 52.0 J 35 20 30
B9.9 B11.0 S8.0-9.7
R1.3 R1.3
Three 224301 2 230 60 1.25 Y10.0 2060 Y13.2 2610 M1.8-2.3 51.0 G 30 20 25
Wire B9.3 B11.9 S5.8-7.2
W-Run R2.6 R2.6
Cap 224302 3 230 60 1.15 Y14.0 2940 Y17.0 3350 M1.0-1.5 83.5 H 45 30 40
(3) B11.2 B12.6 S3.5-4.4
R6.1 R6.0
224303 5 230 60 1.15 Y23.0 4920 Y27.5 5620 M.68-1.0 121.0 F 80 45 60
(4) B15.9 B19.1 S1.8-2.2
R11.0 R10.8
Franklin Single Phase Motors
Single Phase Motor Specifications (60HZ) 3450 RPM
Table 4 (Continued)
Type Motor HP Volts HZ S.F.
Model (2) (2) Res.
Amps Watts Amps Watts M=Main Amps Code
S=Start
(1) Main winding - black to yellow Start winding - red to yellow
(2) Y=yellow lead, line amps B=black lead, main winding amps R=red lead, start winding amps
(3) Control boxes date coded 02C and older have 35MFD run capacitors and the current values will be (Y14.0, B12.2, R4.7 at FL) & (Y17.0, B14.5, R4.5 at SF load).
(4) Control boxes date coded 01M and older have 60MFD run capacitors and the current values will be (Y23.0, B19.1, R8.0 at FL.) & (Y27.5, B23.2, R7.8 at SF load).
Std.
Fuse
Amps
Dual
Element
Time
Delay
Std.
Fuse
Amps
Circuit
Breaker
Or Fuse
Amps
Max Per
NEC
Rated Input
(Full Load)
Maximum
(S.F. Load)
Winding (1)
(Resistance
/Ohms)
Locked
Rotor
KVA
Franklin Three Phase Motors
Three Phase Motor Specifications (60HZ) 3450 RPM
Table 5
Motor KVA
Model HP Volts HZ S.F. Line to Line Locked Code
Ohms Rotor Amps
Amps Watts Amps Watts
234501 1/2 200 60 1.6 2.8 585 3.4 860 6.6-8.4 17.5 N 10 5 8
234511 1/2 230 60 1.6 2.4 585 2.9 860 9.5-10.9 15.2 N 8 5 6
234521 1/2 460 60 1.6 1.2 585 1.5 860 38.4-44.1 7.6 N 4 3 3
234502 3/4 200 60 1.5 3.6 810 4.4 1150 4.6-5.9 23.1 M 15 8 10
234512 3/4 230 60 1.5 3.1 810 3.8 1150 6.8-7.8 20.1 M 10 6 8
234522 3/4 460 60 1.5 1.6 810 1.9 1150 27.2-30.9 10.7 M 5 3 4
234503 1 200 60 1.4 4.5 1070 5.4 1440 3.8-4.5 30.9 M 15 10 15
234513 1 230 60 1.4 3.9 1070 4.7 1440 4.9-5.6 26.9 M 15 8 10
234523 1 460 60 1.4 2.0 1070 2.4 1440 19.9-23.0 13.5 M 6 4 5
234504 1 1/2 200 60 1.3 5.8 1460 6.8 1890 2.5-3.0 38.2 K 20 10 15
234514 1 1/2 230 60 1.3 5.0 1460 5.9 1890 3.2-4.0 33.2 K 15 10 15
234524 1 1/2 460 60 1.3 2.5 1460 3.1 1890 13.0-16.0 16.6 K 8 5 8
234534 1 1/2 575 60 1.3 2.0 1460 2.4 1890 20.3-25.0 13.3 K 6 4 5
234305 2 200 60 1.25 7.7 2150 9.3 2700 1.8-2.4 53.6 L 25 15 20
234315 2 230 60 1.25 6.7 2150 8.1 2700 2.3-3.0 46.6 L 25 15 20
234325 2 460 60 1.25 3.4 2150 4.1 2700 9.2-12.0 23.3 L 15 8 10
234335 2 575 60 1.25 2.7 2150 3.2 2700 14.6-18.7 18.6 L 10 5 8
Std.
Fuse
Amps
Dual
Element
Time
Delay
Std.
Fuse
Amps
Circuit
Breaker
Amps
Rated Input
Maximum
(S.F. Load)
