- 8 -
4200511-E 1/2 115 60 1.60 8.4 880 10 1090 2.0-2.5 25 G 25 15 20
Two 4200531-E 1/2 230 60 1.60 4.2 870 5.1 1050 7.2-8.8 14 H 15 10 10
Wire 4200731-E 3/4 230 60 1.50 4.8 1040 6.1 1325 5.7-7.1 17 F 15 10 15
4201031-E 1 230 60 1.40 7 1570 8 1820 4.7-5.8 22 E 20 15 20
4201531-E 1 1/2 230 60 1.30 9 1980 10.6 2350 2.7-3.3 34 F 30 20 25
4300511-E 1/2 115 60 1.60 Y9.0 690 Y11.0 1020 M1.5-1.9 41 L 30 20 30
B9.0 B11.0 S3.1-3.9
R0 R0
4300531-E 1/2 230 60 1.60 Y5.0 720 Y5.6 1055 M6.2-7.7 18 K 20 10 15
B5.0 B5.6 S13.0-16.0
Three R0 R0
Wire 4300731-E 3/4 230 60 1.50 Y6.2 980 Y7.4 1390 M4.0-4.9 29 K 20 15 20
B6.2 B4.0 S9.5-11.6
R0 R0
4301031-E 1 230 60 1.40 Y7.4 1235 Y9.0 1670 M3.3-4.1 39 K 25 15 25
B7.4 B9.0 S11.9-14.6
R0 R0
4301531-E 1 1/2 230 60 1.30 Y8.9 1685 Y10.7 2170 M2.6-3.3 43 H 30 20 25
B8.5 B10.4 S8.0-9.8
R1.3 R1.2
Three 4302031A 2 230 60 1.25 Y9.9 2170 Y12.2 2660 M1.6-2.2 49 G 30 20 25
Wire B9.1 B11.7 S4.8-5.9
W-Run R2.6 R2.6
Cap 4303031A 3 230 60 1.15 Y14.3 3170 Y16.5 3620 M1.0-1.4 76 G 45 25 40
(3) B12.0 B13.9 S2.0-2.5
R5.7 R5.6
4305031A 5 230 60 1.15 Y24.0 5300 Y27.0 6030 M.6-.8 101 E 80 45 60
(4) B19.1 B22.0 S1.3-1.7
R10.2 R10.0
Faradyne Single Phase Motors
Single Phase Motor Specifications (60HZ) 3450 RPM
Table 4A
Type Motor HP Volts HZ S.F.
Model (2) (2) Res.
Amps Watts Amps Watts M=Main Amps Code
S=Start
(1) Main winding - black to yellow Start winding - red to yellow.
(2) Y=yellow lead, line amps B=black lead, main winding amps R=red lead, start winding amps
Std.
Fuse
Amps
Dual
Element
Time
Delay
Std.
Fuse
Amps
Circuit
Breaker
Or Fuse
Amps
Max Per
NEC
Rated Input
(Full Load)
Maximum
(S.F. Load)
Winding (1)
(Resistance
/Ohms)
Locked
Rotor
KVA
Franklin Three Phase Motors
Three Phase Motor Specifications (60HZ) 3450 RPM
Table 5 (Continued)
Motor KVA
Model HP Volts HZ S.F. Line to Line Locked Code
Ohms Rotor Amps
Amps Watts Amps Watts
234306 3 200 60 1.15 10.9 2980 12.5 3420 1.3-1.7 71.2 K 35 20 30
234316 3 230 60 1.15 9.5 2980 10.9 3420 1.8-2.2 61.9 K 30 20 25
234326 3 460 60 1.15 4.8 2980 5.5 3420 7.2-8.8 31 K 15 10 15
234336 3 575 60 1.15 3.8 2980 4.4 3420 11.4-13.9 24.8 K 15 8 10
234307 5 200 60 1.15 18.3 5050 20.5 5810 .74-.91 122 K 60 35 50
234317 5 230 60 1.15 15.9 5050 17.8 5810 1.0-1.2 106 K 50 30 40
234327 5 460 60 1.15 8.0 5050 8.9 5810 4.0-4.9 53.2 K 25 15 20
234337 5 575 60 1.15 6.4 5050 7.1 5810 6.4-7.8 42.6 K 20 15 20
234308 7 1/2 200 60 1.15 26.5 7360 30.5 8450 .46-.57 188 K 90 50 70
234318 7 1/2 230 60 1.15 23.0 7360 26.4 8450 .61-.75 164 K 80 45 60
234328 7 1/2 460 60 1.15 11.5 7360 13.2 8450 2.5-3.1 81.9 K 40 25 30
234338 7 1/2 575 60 1.15 9.2 7360 10.6 8450 4.0-5.0 65.5 K 30 20 25
234595 10 460 60 1.15 15.9 10000 17.3 11400 1.8-2.3 116 L 60 30 45
234598 10 575 60 1.15 12.5 10000 13.6 11400 2.8-3.5 92.8 L 45 25 35
Std.
Fuse
Amps
Dual
Element
Time
Delay
Std.
Fuse
Amps
Circuit
Breaker
Amps
Rated Input
Maximum
(S.F. Load)
To Next Page
