1.2 Module Unpacking and Handling
The battery is always boxed with the accessories, but the structure/shelf rack is not included and needs to be ordered separately.
ATTENTION:
The battery must be lifted by four persons, using lifting devices
Lift the battery up and put vertical into the carton, then use a mechanical lifting device to install the battery into the shelf.
1.2.1 Package Information and System Configuration List
Upon receipt, review the configuration list carefully to make sure that the battery box and accessories are received in the
correct quantities and type, and visually inspect to ensure that they are free from damage.
1.3 Rack mount 19`` front holes
NOTE: Each module is equipped with 4 fixing holes, each module must be secured to the rack structure before
installing another one.
1.3.1 Dimensions
To Next Page
