Weco ESS 5K3-XP - Parallel LV Connection and System Rack Configuration

WECO 5K3-XP RACK LV-EMEA
20
Version 11/11/2021
L
O
W
V
O
L
T
A
G
E
SECTION II – LOW VOLTAGE CONFIGURATION
3 PARALLEL LV CONNECTION AND SYSTEM RACK CONFIGURATION
ATTENTION:
Before operating make sure that the voltage is equal to 0 Vdc
Battery must be turned off before starting any activity
All drawings and images are for reference only. Always refer to the physical product as the standard.
If the manual does not match the physical product, stop all actions, remove any connections,
and store them in a safe place. Call your WeCo technical service representative for assistance.
