Weco ESS 5K3-XP User Manual

WECO 5K3-XP RACK LV-EMEA
33
Version 11/11/2021
L
O
W
V
O
L
T
A
G
E
3.5 Module Specifications
5K3-XP RACK LV
Individual Module Setting
Nominal DC Voltage
51.2
Nominal Amp Hours
105
Rated kWh Capacity
5.37 kWh
Standard Charge Current
50 Adc
Max Charge Current
100A
Standard Discharging Current
(open Loop)
50A Adc
Max Discharging Current
200 Adc Peak 5 sec before protection
Min Voltage (Open Loop)
50.5 Vdc
Max Voltage (Open Loop)
55.5 Vdc
Charging Current at Various Vdc at 77°F
(25°C)
From 50.5 Vdc up to 54.2 Vdc
50A (protection above 100A)
From 54.2 Vdc up to 55.5 Vdc
Max 10A
Operative Ambient Temperatures
Without CAN Communication
From +50°F to +95°F (+10°C to +35°C)
Max Cell Temp. +45°C Min Cell Temp +15°C
Operating Efficiency
Up to 98%
Self-Discharge Rate
1% self-discharge per month @ 77°F (25°C)
Memory Effect
None
Warranty Period
see Limited Warranty terms
Note
Without CAN communication, it is not always possible to perform a correct calibration of the cells due to the lack of interaction
with the inverter. It is therefore possible that the SoC 100% threshold is not reached.
It is recommended to use the minimum and maximum settings indicated, and to monitor the charging process to ensure that
the battery does not go into protection mode for Low or High Voltage, Temperature or Current.
Some inverter Logic or Battery protocol Logic could not allow the battery to reach the 0% in order to prevent the inverter
shutdown * (DC Powered)
Use conservative settings in order to respect the Limited Warranty Parameters and avoid damages to the battery, such
Overvoltage, Undervoltage, Over or Under Temperatures
