REPAIR PARTS
TRACTOR - - MODEL NUMBER WEX145H42B
ELECTRICAL
KEY PART
NO. NO. DESCRIPTION
1 144925 Battery 12 Volt 25 AMP
2 74760412 Bolt Hex Hd 1/4-20unc X 3/4
8 156417 Case Battery
16 153664 Switch Interlock Push-In
19 10090400 Washer Lock 1/4
20 73350400 Nut Jam Hex 1/4-20 Unc
21 136850 Harness Asm Light W/4152j
22 4152J Bulb Light #1156
24 4799J Cable Battery 6 Ga 11" red
25 146147 Cable Battery 6 Ga 44" red
26 108824X Fuse 30 AMP Auto Green
27 73510400 Nut Keps Hex 1/4-20unc
28 4207J Cable Ground 6 Ga 12" black
29 121305X Switch Plunger Nc Gray
30 140301 Switch Ign 4 pos w/lights
31 124211X Nut Ignition
32 141226 Cover Sw Ignition
33 122147X Key Ign Modleded Generic
40 156442 Harness Ignition LT PL Mech
41 71110408 Bolt Blk Fin Hex 1/4 - 20 x 1/2
42 131563 Cover Terminal Red
43 145673 Solenoid
44 73640400 Nut Keps Hex 1/4-20 Unc
48 140844 Adapter Ammeter
52 141940 Protection Wire Loop
70 140422 Harness, Eng.
NOTE: All component dimensions give in U.S. inches
1 inch = 25.4 mm.
