7
REPAIR PARTS
TRACTOR - - MODEL NUMBER WEX145H42B
CHASSIS AND ENCLOSURES
KEY PART
NO. NO. DESCRIPTION
1 160393 Chassis LT Stamping 98
2 140356 Drawbar, Stretch 94
3 17490612 Screw, Thdrol. 3/8-16 x 3/4 Ty-TT
4 19131216 Washer 13/32 x 3/4 x 16 Gauge
5 155272 Bumper Hood/Dash
6 155923 Saddle LT Fender Shift
8 155138 Clip Retainer Slide-On
9 161937X011 Dash P/L
10 72140608 Bolt, Rdhd Sqnk 3/8-16 x 1
11 155927 Panel Asm.Dash LH
12 145660 Clip Tinnerman Grille P/L
13 155934X010 Dash, Panel RH
14 17490608 Screw Thdrol 3/8-16 x 1/2 Ty-tt
15 74180512 Screw Mach.Trhd 5/16-18 UNC x 3/4
16 73510500 Nut Keps 5/16-18 UNC
17 159639X550 Hood Pnt Stl PL
18 126938X Bumper Hood
24 74780616 Bolt, Hex , Fin. 3/8-16UNC x 1 Gr. 5
25 19131312 Washer 13/32 x 13/16 x12 Gauge
26 73800600 Nut Lock Hex w/Ins. 3/8-16 Unc
28 157373 Grille
29 140273 Lens Grille
30 157583X550 Fender Pnt
31 136619 Bracket Fender
33 105476X550 Footrest Pnt., LH
34 105475X550 Footrest Pnt., RH
35 72110606 Bolt Rdhd Sht. Sqnk 3/8-16 X 3/4
37 17490508 Screw Thdrol 5/16-18 x 1/2 Tyt
38 139886 Bracket Asm. Pvt. LH Mower Rear
39 139887 Bracket Asm. Pvt. RH Mower Rear
51 73800400 Nut Lock Hex W/Ins 1/4-20
52 19091416 Washer 9/32 x 7/8 x 16 Ga.
53 144697 Bracket, Grille LH
54 161464 Screw Hex WSHD 8-18 x 7/8
55 144696 Bracket Grille RH
57 74780412 Bolt Fin Hex 1/4-20 x 3/4
58 150127 Air Duct Engine P/L
140 158418 Bracket Suspension Front
145 156524 Rod Pivot Chassis/Hood
- - 5479J Plug Btn Blk .359 Dia Ch/Inf
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
