Infrared Remote Control and I/O
Expansion Module
English
10 | CFW100
Param. Description Adjustable Range
Factory
Setting
Proper.
P375
(*)
NTC
Temperature
0 to 100 °C ro
P840
(*)
Control
Key Status
2 or 802 = On/Off
6 or 806 = Arrow down
8 or 808 = Arrow up
9 or 809 = Forward/Reverse
B or 80B = Programmer
F or 80F = Special
Function 01
10 or 810 = Special
Function 02
11 or 811 = Special
Function 03
ro
P842
(*)
Quick
view 1 IR
0 to 999 2
P843
(*)
Quick
view 2 IR
0 to 999 375
NOTE!
(*) Parameters available only when the
accessory is connected.
6 USE OF THE ACCESSORY
For the proper operation of the CFW100 frequency
inverter with the CFW100-IOADR accessory, some
procedures must be observed:
1. The remote control must be directed to the cable end
(IR receiver), as shown in Figure A2 on page 30.
2. The maximum distance between the remote control
and IR receiver is eight meters.
NOTE!
Before using the infrared remote control,
remove the battery protection in the lower
part of the control.
Periodically check the need to replace the
remote control battery.
The functionalities of the remote control keys can be
seen in Table 4 on page 11. The remote control can
be seen in Figure 1 on page 11.
