Infrared Remote Control and I/O

Expansion Module

English

6 | CFW100

 Installation, configuration and operation guide.

4 INSTALLATION OF THE ACCESSORY

The CFW100-IOADR is easily connected to the CFW100

frequency inverter by means of the plug-and-play

concept. The procedures below must be observed for

the proper installation and start-up:

1. With the inverter powered down, remove the front

cover from the inverter (Figure A1 on page 29).

2. Fit the accessory to be installed as shown in Figure

A1 on page 29.

3. Fit the cable with the IR receiver in “P1” on the

accessory as shown in Figure A1 on page 29.

4. Power up the inverter.

5 CONFIGURATIONS

The CFW100-IOADR connections must be done to the

I/O expansion connector as per Table 1 on page 7.

The pins of the accessory connector are shown in Figure

A3 on page 30.
