REFERENCIA RÁPIDA DE LOS PARÁMETROS, ALARMAS Y FALLAS
Parám. Descripción Rango de Valores Ajuste de Fábrica Prop.
P680 Estado Lógico 0 a FFFF (hexa)
Bit 0 = Reservado
Bit 1 = Comando Gira
Bit 2 = Fire Mode
Bit 3 a 4 = Reservado
Bit 5 = 2ª Rampa
Bit 6 = Modo Config.
Bit 7 = Alarma
Bit 8 = Girando
Bit 9 = Habilitado
Bit 10 = Horario
Bit 11 = JOG
Bit 12 = Remoto
Bit 13 = Subtensión
Bit 14 = Reservado
Bit 15 = Falla
ro
P681 Velocidad 13 bits 0 a FFFF (hexa) ro
P682 Control Serial/USB 0 a FFFF (hexa)
Bit 0 = Habilita Rampa
Bit 1 = Habilita General
Bit 2 = Girar Horario
Bit 3 = Habilita JOG
Bit 4 = Remoto
Bit 5 = 2ª Rampa
Bit 6 = Reservado
Bit 7 = Reset de Falha
Bit 8 a 15 = Reservado
ro
P683 Ref. Vel. Serial/USB 0 a FFFF (hexa) ro
P684
(*)
Control CO/DN 0 a FFFF (hexa)
Bit 0 = Habilita Rampa
Bit 1 = Habilita General
Bit 2 = Girar Horario
Bit 3 = Habilita JOG
Bit 4 = Remoto
Bit 5 = 2ª Rampa
Bit 6 = Reservado
Bit 7 = Reset de Falla
Bit 8 a 15 = Reservado
ro
P685
(*)
Ref. Vel. CO/DN 0 a FFFF (hexa) ro
P690 Estado Lógico 2 0 a FFFF (hexa)
Bit 0 a 2 = Reservado
Bit 3 = Ahorrador de Energía
Bit 4 = Reducción Fs
Bit 5 = Reservado
Bit 6 = Rampa de Desaceleración
Bit 7 = Rampa de Aceleración
Bit 8 = Rampa Congelada
Bit 9 = Setpoint Ok
Bit 10 = Regulación Link DC
Bit 11 = Config. en 50 Hz
Bit 12 = Ride-Through
Bit 13 = Flying Start
Bit 14 = Frenado CC
Bit 15 = Pulsos PWM
ro
P700
(*)
Protocolo CAN 1 = CANopen
2 = DeviceNet
P701
(*)
Dirección CAN 0 a 127 63
P702
(*)
Tasa Comunicación CAN 0 = 1 Mbps/Auto
1 = Reservado/Auto
2 = 500 Kbps
3 = 250 Kbps
4 = 125 Kbps
5 = 100 Kbps/Auto
6 = 50 Kbps/Auto
7 = 20 Kbps/Auto
8 = 10 Kbps/Auto
0
P703
(*)
Reset de Bus Off 0 = Manual
1 = Automatico
1
CFW100 | 37
