What causes E01 DC Link Overvoltage in WEG Inverters and how to fix it?
The E01 error on your WEG Inverter indicates a DC Link Overvoltage. This can be due to: * Power supply voltage being too high: Check and adjust the power supply voltage. * Load inertia being too high or deceleration ramp too short: Adjust the load inertia or deceleration ramp settings. * P151 setting being too high: Lower the setting of P151.
Why does my WEG Inverter show E04 Inverter Overtemperature and how can I resolve it?
The E04 error on a WEG Inverter signals an overtemperature condition. This can occur if: * The ambient temperature is too high (above 40°C) or the output current is too high: Ensure the ambient temperature is below 40°C and lower the output current. * The blower is locked or defective: Check, repair, or replace the blower.
What to do if WEG Inverter displays E05 Motor/Inverter Overload Ixt Function error?
If your WEG Inverter shows error E05, indicating a Motor/Inverter Overload, consider these possibilities: * P156 is set too low for the motor being used: Increase the setting of P156. * The motor is under an actual overload condition: Remove the overload condition from the motor.
How to troubleshoot E14 Self-Tuning Fault on a WEG CFW08 Vector?
If your WEG Inverter displays an E14 error, indicating a Self-Tuning Fault, check the following: * Motor connection: Ensure the motor is connected to the inverter output. * Motor wiring: Verify correct motor connection (voltage, phase). * Motor size: Replace with a compatible motor if the used motor is too small for the inverter (P401
What causes E31 Keypad (HMI) Connection Fault on WEG Inverters?
The E31 error on your WEG Inverter indicates a Keypad (HMI) Connection Fault. This can be due to: * Keypad cable misconnection: Recheck and correct the keypad cable connections. * Electrical noise: Reduce electrical noise in the installation.
What does E06 External Fault mean on my WEG CFW08 Vector and how to fix it?
The E06 error on your WEG Inverter indicates an External Fault. This occurs when Ani DI (DI3 and/or DI4) programmed for external fault detection is open (not connected to GND - XC1). To resolve it, check and connect DI3 or DI4 to GND.
What causes E10 Keypad Error on a WEG CFW08 Vector Inverter?
The E10 error on your WEG Inverter indicates a Keypad Error. This can occur due to: * Defective contact in the HMI-CFW08-RS cable: Check and replace the HMI-CFW08-RS cable. * Electrical noise: Reduce electrical noise in the installation (electromagnetic interference).
What does E08 CPU Error (Watchdog) mean on a WEG Inverter?
The E08 error on your WEG Inverter indicates a CPU Error (Watchdog). This is due to electrical noise. Reduce electrical noise in the installation.
General| Frequency Range | 0 to 300 Hz |
|---|---|
| Overload Capacity | 150% for 60 seconds |
| Protection Degree | IP20 |
| Communication | RS485, Modbus RTU |
| Voltage | 200 V to 240 V |
| Control Mode | Vector Control |
| Ambient Temperature | -10°C to 50°C |
| Input Frequency | 50 Hz / 60 Hz |
| Output Voltage | 0 to input voltage |
| Braking | Dynamic braking resistor (optional) |
| Protection Features | Overcurrent, overvoltage, undervoltage, overtemperature |
| Operating Temperature | -10°C to 50°C |
| Cooling Method | Forced air cooling (fan) |
| Humidity | 5% to 90% non-condensing |
General safety warnings and guidelines within the manual.
Essential advice for qualified personnel before installation and operation.
Overview of the manual's content, structure, and purpose.
Description of the CFW-08 drive, its features, and versions.
Comparison of accessories and features between previous and current models.
Details on how to identify the CFW-08 model, including nameplate information.
Procedures for the physical installation and mounting of the CFW-08 inverter.
Recommendations for the installation location and environmental conditions.
Recommended free spaces and dimensional data for inverter installation.
Guidelines for electrical connections, power, grounding, and control wiring.
Instructions for making AC input power and protective earth connections.
Details on making control wiring for analog and digital inputs/outputs.
Guidelines for ensuring EMC compliance during installation.
Essential checks before applying power to the inverter.
Steps for powering up the inverter and verifying successful operation.
Procedure for starting up with keypad in Linear V/F control.
Procedure for starting up using terminals in Linear V/F control.
Procedure for starting up with keypad in Vector control.
Overview of the CFW-08 keypad, its display, LEDs, and keys.
How to use the keypad for operation, diagnostics, and programming.
Detailed description of keypad key functions and operation modes.
How to view and change inverter parameters using the keypad.
Glossary of symbols used in parameter descriptions.
Concepts related to the CFW-08 frequency inverter and control modes.
Description of V/F and Vector control modes available in the CFW-08.
Explanation of the sensorless vector control mode and its benefits.
Categorization of parameters for easier understanding and reference.
Parameters for configuring motor characteristics for optimal performance.
Parameters for special functions like PID control.
Introduction to the PID regulator for closed-loop process control.
Identification and causes of inverter faults, with reset procedures.
Common problems, points to check, and corrective actions for troubleshooting.
Recommendations for routine inspections and maintenance to ensure longevity.
Procedures for cleaning the inverter's cooling system and electronic boards.
Description and dimensions of the parallel HMI keypad.
Information on the external serial keypad for copy function.
How to use the keypad to copy settings between inverters.
RS-232 serial communication module for PC/PLC connection.
Importance and installation of RFI filters to prevent EMI.
Use of dynamic braking for short deceleration or high inertia loads.
Guidelines for selecting the appropriate braking resistor.
Introduction to serial communication for inverter networking.
Physical connection standards for serial communication (RS-232, RS-485).
Details on the RS-232 interface for point-to-point connections.
Introduction to Modbus-RTU protocol for inverter communication.
How the CFW-08 operates as a slave in a Modbus-RTU network.
Configuring inverter address, transfer rate, and parity for network communication.
Defining the inverter's address within the Modbus-RTU network.
Electrical and mechanical specifications of the CFW-08 inverter series.
Power specifications for 200-240V models, including current and dimensions.
Power specifications for 380-480V models, including current and dimensions.
General electronic data, control methods, inputs, outputs, and safety features.
Conditions and limitations of the WEG warranty for CFW-08 inverters.
