WEG CFW08 Vector inverter User Manual

140
CFW-08 OPTIONS AND ACCESSORIES
3) Master:
EOT
Reading of the output current from the inverter 10
(supposing the the same was at 7.8A at the moment of the enquiry).
1) Master:
EOT J 0 1 7 0 3 ENQ
P003 Code
addr.10
2) Inverter:
P003 Code
P003=30CH=780=7.8/0.01
addr.10
3) Master:
EOT
8.19.5 Variables and Errors
of the Serial
Communication
8.19.5.1 Basic Variables
8.19.5.1.1 V00 (code 00700)
Indication of the inverter model (reading variable).
The reading of this variable permits the identification of the inverter
type. For the CFW-08 this values is 7, as defined in 8.21.3.7.
8.19.5.1.2 V02 (code 00702)
Indication of the inverter status (reading variable)
Logical status (byte-high)
Error code (byte-low)
where:
Logical Status:
EL15 EL14 EL13 EL12 EL11 EL10 EL9 EL8
J STX 0 1 7 0 3 = 0H 3H 0H CH ETX BCC

WEG CFW08 Vector inverter Specifications

General

Frequency Range	0 to 300 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Communication	RS485, Modbus RTU
Voltage	200 V to 240 V
Control Mode	Vector Control
Ambient Temperature	-10°C to 50°C
Input Frequency	50 Hz / 60 Hz
Output Voltage	0 to input voltage
Braking	Dynamic braking resistor (optional)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Operating Temperature	-10°C to 50°C
Cooling Method	Forced air cooling (fan)
Humidity	5% to 90% non-condensing
