WEG CFW08 Vector inverter User Manual

44
INSTALLATION AND CONNECTION
3.3.2 Inverter Models and Filters
Table 3.6 below shows the inverter models and the respective RFI filter
and the EMC category number. A description of each EMC category is
given in item 3.3.3. The characteristics of the footprint and external input
RFI filters are given in item 3.3.4.
Id Inverter Model
1 CFW080016S2024...FAZ
2 CFW080026S2024...FAZ
3 CFW080040S2024...FAZ
4
CFW080016B2024...FAZ
(single-phase input)
5
CFW080026B2024...FAZ
(single-phase input)
6
CFW080040B2024...FAZ
(single-phase input)
7
CFW080073B2024...FAZ
(single-phase input)
8
CFW080100B2024...FAZ
(single-phase input)
9 CFW080016S2024...
10 CFW080026S2024...
11 CFW080040S2024...
12
CFW080016B2024...
(single-phase input)
13
CFW080026B2024...
(single-phase input)
14
CFW080040B2024...
(single-phase input)
15
CFW080016B2024...
(three-phase input)
16
CFW080026B2024...
(three -phase input)
17
CFW080040B2024...
(three -phase input)
18 CFW080070T2024...
19
CFW080073B2024...
(single-phase input)
20
CFW080073B2024...
(three-phase input)
21
CFW080100B2024...
(single-phase input)
22
CFW080100B2024...
(three-phase input)
23 CFW080160T2024...
24 CFW080010T3848...FAZ
25 CFW080016T3848...FAZ
26 CFW080026T3848...FAZ
27 CFW080040T3848...FAZ
28 CFW080027T3848...FAZ
29 CFW080043T3848...FAZ
30 CFW080065T3848...FAZ
31 CFW080100T3848...FAZ
32 CFW080130T3848...FAZ
33 CFW080160T3848...FAZ
Input RFI Filter
Built-in filter
[ FEX1-CFW08
(footprint filter) ]
Built-in filter
FS6007-16-06
(external filter)
FS3258-7-45
(external filter)
FN3258-16-45
(external filter)
FS6007-25-08
(external filter)
FN3258-16-45
(external filter)
FS6007-36-08
(external filter)
FN3258-16-45
(external filter)
FN3258-30-47
(external filter)
Built-in filter
[ FEX2-CFW08
(footprint filter) ]
Built-in filter
EMC Category
Category I (industrial)
Category II (domestic)
Category I (industrial)
Dimensions
(Width x Height x Depth)
79x190x182mm
115x200x150mm
Inverter: 75x151x131mm
Filter: 85.5x119x57.6mm
Inverter: 75x151x131mm
Filter: 40x190x70mm
Inverter: 75x151x131mm
Filter: 45x250x70mm
Inverter: 115x200x150mm
Filter: 85.5x119x57.6mm
Inverter: 115x200x150mm
Filter: 45x250x70mm
Inverter: 115x200x150mm
Filter: 85.5x119x57.6mm
Inverter: 115x200x150mm
Filter: 45x250x70mm
Inverter: 115x200x150mm
Filter: 50x270x85mm
79x190x182mm
115x235x150mm
143x203x165mm

WEG CFW08 Vector inverter Specifications

General

Frequency Range	0 to 300 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Communication	RS485, Modbus RTU
Voltage	200 V to 240 V
Control Mode	Vector Control
Ambient Temperature	-10°C to 50°C
Input Frequency	50 Hz / 60 Hz
Output Voltage	0 to input voltage
Braking	Dynamic braking resistor (optional)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Operating Temperature	-10°C to 50°C
Cooling Method	Forced air cooling (fan)
Humidity	5% to 90% non-condensing
