WEG CFW08 Vector inverter User Manual

141
CFW-08 OPTIONS AND ACCESSORIES
EL8: 0 = ramp enabling (start/stop) inactive
1 = ramp enabling
EL9: 0 = general enabling inactive
1 = general enabling active
EL10: 0 = Reverse
1 = Forward
EL11: 0 = JOG inactive
1 = JOG active
EL12 0 = local
1 = remote
EL13: 0 = without undervoltage
1 = with undervoltage
EL14 : not used
EL15: 0 = without error
1 = with error
Inverter
enabled
EL8=EL9=1
}
8.19.5.1.3 V03 (code 00703)
Error Code: hexadecimal error number
Ex.: E00 00H
E01 01H
E10 0AH
→
→
→
Selection of the Logical Control
Writing variable, whose bits have the following meaning:
BYTE HIGH : desired action mask. It order to enable the action, the
corresponding bit should be set to 1.
BYTE LOW: logical level of the desired action.
CL8: 1 = enabling ramp (start/stop)
CL9: 1 = general enabling
CL10: 1 = forward/reverse rotation
CL11: 1 = JOG
CL12: 1 = local/remote
CL13: not used
CL14: not used
CL15: 1 = inverter “RESET”
CL15 CL14 CL13 CL12 CL11 CL10 CL9 CL8
MSB LSB
CL7 CL6 CL5 CL4 CL3 CL2 CL1 CL0
MSB LSB
CL0: 1 = enabling (run)
0 = disabling by ramp (stop)
CL1: 1 = enabling
0 = general disabling (stops by inertia)
CL2: 1 = forward
0 = reverse
CL3: 1 = JOG active
0 = JOG inactive
CL4: 1 = remote
0 = local

WEG CFW08 Vector inverter Specifications

General

Frequency Range	0 to 300 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Communication	RS485, Modbus RTU
Voltage	200 V to 240 V
Control Mode	Vector Control
Ambient Temperature	-10°C to 50°C
Input Frequency	50 Hz / 60 Hz
Output Voltage	0 to input voltage
Braking	Dynamic braking resistor (optional)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Operating Temperature	-10°C to 50°C
Cooling Method	Forced air cooling (fan)
Humidity	5% to 90% non-condensing
