CFW-08 OPTIONS AND ACCESSORIES
- IDENTIFICATION
network address;
inverter;
software version.
- CONTROL
general enabling/disabling;
enabling/disabling by ramp;
direction of rotation;
frequency/speed reference;
local/remote;
JOG;
error and fault RESET.
- STATUS RECOGNITION
ready;
Sub;
run;
local/remote;
error;
JOG;
direction of rotation.
- PARAMETER READING
- CHANGE OF PARAMETERS
Typical examples of network use:
PC (master) for the parametrization of one or several inverters at the
same time;
SDCD monitoring inverter variables;
PLC controlling the operation of one or more inverters in a industrial
process.
8.19.2 Interfaces Description
The physical connection between the inverters and the master is performed
according to one of the standards below:
a. RS-232 (point-to-point up to 10m);
b. RS-485 (multipoint, galavanic isolation, up to 1000m);
8.19.2.1 RS-485
This interface permits the linkage of up to 30 inverters to a master (PC,
PLC, etc.), attributing and setting for each inverter an address (1 to 30). In
addition to these 30 addresses, there are two addresses to perform special
tasks:
Address 0: any inverter in the network is inquired, independently of its
address. Only one inverter can be connected to the network (point-to-
point) in order to prevent short-circuits in the line interface.

WEG CFW08 Vector inverter Specifications

General

Frequency Range	0 to 300 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Communication	RS485, Modbus RTU
Voltage	200 V to 240 V
Control Mode	Vector Control
Ambient Temperature	-10°C to 50°C
Input Frequency	50 Hz / 60 Hz
Output Voltage	0 to input voltage
Braking	Dynamic braking resistor (optional)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Operating Temperature	-10°C to 50°C
Cooling Method	Forced air cooling (fan)
Humidity	5% to 90% non-condensing
