SSW-06 - QUICK PARAMETER REFERENCE
10
Parameter Description Adjustable Range
Factory
Unit
User´s
Page
Setting Setting
P042 Time Powered 0 to 65530 - h 81
P043 Time Enabled 0 to 6553 - h 82
P050 Motor Thermal Protection Status 0 to 250 - % 82
P085 Fieldbus Communication Board Status 0=Off - - 82
1=Board Inactive
2=Board Active and Offline
3=Board Active and Online
REGULATION PARAMETERS P100 TO P199
Voltage Ramp
P101 Initial Voltage (% Un of the motor) 25 to 90 30 % 82
P102 Acceleration Ramp Time 1 to 999 20 s 83
P103 Deceleration Voltage Step 100=Inactive 100=Inactive % 84
(% Un of the motor) 99 to 60
P104 Deceleration Ramp Time 0=Inactive 0=Inactive s 84
1 to 299
P105 End Deceleration Voltage 30 to 55 30 % 84
(% Un of the Motor)
Current Limit
P110 Current Limit 150 to 500 300 % 84
(%In of the Motor current)
P111 Initial Current for the Current Ramp 150 to 500 150 % 85
(% In of the Motor)
P112 Time for the Current Ramp 1 to 99 20 % 85
(% of P102)
Torque Control
P120
(1)
Starting Torque Characteristics 1=Constant 1=Constant - 86
2=Linear
3=Quadratic
P121 Initial Starting Torque (% Tn of Motor) 10 to 400 30 % 87
P122 End Starting Torque (% Tn of Motor) 10 to 400 110 % 87
P123 Minimum Starting Torque 10 to 400 27 % 87
(% Tn of the Motor)
P124 Time for the Minimum Start Torque 1 to 99 20 % 87
(% of P102)
P125
(1)
Stopping Torque Characteristics 1=Constant 1=Constant - 88
2=Linear
3=Quadratic
P126 End Stop Torque (% Tn of the Motor) 10 to 100 20 % 88
P127 Minimum Stop Torque 10 to 100 50 % 89
(% Tn of the Motor)
P128 Time for the Minimum Stop Torque 1 to 99 50 % 89
(% of P104)
Pump Control
P130
(1)
Pump Control 0=Pump I 0=Pump I - 89
1=Pump II
By-pass
P140
(1)
External By-pass Contactor 0=Inactive 0=Inactive - 89
1=Active
To Next Page
