Wega ORION Series User Manual

50 of 68
TECHNICIANS manual
Description
Control
unit code
Giemme Gicar
SPHERA
1-2-3GR
120V 18090013 par. 14.7.7
230V 18090012 par. 14.7.7
4GR
120V 18090015 par. 14.7.7
230V 18090014 par. 14.7.7
SPHERA
DISPLAY
1-2-3-4GR
120V 18090019 par. 14.7.8
230V 18090018 par. 14.7.8
START
1-2-3GR
120V 18090030 par. 14.7.5 par. 14.7.6
230-240V 18090031 par. 14.7.5 par. 14.7.6
VENERE
1-2-3GR
120V 18090047 par. 14.7.9 par. 14.7.10
230V 18090048 par. 14.7.9 par. 14.7.10
VENERE
DISPLAY
1-2-3GR
120V 18090079 par. 14.7.11
230-240V 18090080 par. 14.7.11
VELA
1-2-3-4GR
120V 18090079 par. 14.7.11
230V 18090080 par. 14.7.11
14.7 EVD-DISPLAY version
The table below shows, for each model of machine,
the code for the control unit and the reference to the
page with the wiring diagram.
Description
Control
unit code
Giemme Gicar
ATLAS
JUN
120V 18363 par. 14.7.1
230V 18362 par. 14.7.1
1-2-3GR
120V 18090030 par. 14.7.5 par. 14.7.6
230-240V 18090031 par. 14.7.5 par. 14.7.6
ALTAIR
1-2-3GR
120V 18090030 par. 14.7.5 par. 14.7.6
230-240V 18090031 par. 14.7.5 par. 14.7.6
COMBINOVA
JUN
120V 18363 par. 14.7.1
230V 18362 par. 14.7.1
ESPRESSA
1-2-3GR
120V 18090017 par. 14.7.3 par. 14.7.4
230V 18090016 par. 14.7.3 par. 14.7.4
1-2-3GR
120V 18090030 par. 14.7.5 par. 14.7.6
230-240V 18090031 par. 14.7.5 par. 14.7.6
NOVA
JUN
120V 18363 par. 14.7.1
230V 18362 par. 14.7.1
1-2-3GR
120V 18078 par. 14.7.2
230V 18079 par. 14.7.2
4GR 230V 18077 par. 14.7.2
ORION
1-2-3GR
120V 18090017 par. 14.7.3 par. 14.7.4
230V 18090016 par. 14.7.3 par. 14.7.4
1-2-3GR
120V 18090030 par. 14.7.5 par. 14.7.6
230-240V 18090031 par. 14.7.5 par. 14.7.6
POLARIS
1-2-3GR
120V 18090047 par. 14.7.9 par. 14.7.10
230V 18090048 par. 14.7.9 par. 14.7.10
POLARIS
DISPLAY
1-2-3GR
120V 18090079 par. 14.7.11
230V 18090080 par. 14.7.11
1-2-3GR
120V 18090051 par. 14.7.12
230V 18090052 par. 14.7.12
