WEICHAI R6160 Series - Check the V-belt

R660系列柴油机维修保养手册
--
Maintenace Manual For R660 Series Diesel Engine
检查三角皮带的张紧程度
Check the V-belt
传动用三角皮带，使用一段时间后，
应检查其张紧程度，过松时，应调整或更
换。
Check the tension of the V-belt when it is
used for a period of time. Adjust or replace
if necessory.
松开紧固张紧轮的螺栓，变动张紧
轮的位置，直至皮带张紧适中。拧紧张紧
轮紧固螺栓，固定好张紧轮。
Unscrew the bolt for tightening the tension
pulley, change the position of tension
pulley to adjust the tension of pulley. Then
screw down the tension pulley bolt and fix
the pulley.
