10
15. Route the Long Cable (23) around the ÒVÓ-
Pulley (6) on the Right Arm (48). Be sure
that the Cable is in the groove of the ÒVÓ-
Pulley and that the Long Cable Trap (50) is
turned to hold the Cable in place. Tighten
the 3/8Ó x 2 1/2Ó Bolt (7) and the 3/8Ó Nylon
Locknut (not shown).
16. Route the Long Cable (23) around the 3 1/2Ó
Pulley (15) attached to the Pulley Bracket
(20). Be sure that the Cable is in the
groove of the Pulley and that the Cable
Trap (66) is turned to hold the Cable in
place. Tighten the 3/8Ó x 2Ó Bolt (12) and the
3/8Ó Nylon Locknut (not shown).
Be sure that the 5/16Ó x 5Ó Bolt (68) is proper-
ly tightened and that the Pulley Bracket (20)
can move freely.
17. See the inset drawing. Attach a 3 1/2Ó Pulley
(15) and a Cable Trap (66) to the indicated
hole in the Long ÒUÓ-Bracket (57) with a 3/8Ó x
2Ó Bolt (12) and a 3/8Ó Nylon Locknut (21). Be
sure that the Cable Trap is inside the ÒUÓ-
Bracket. Note: This may come pre-assem-
bled.
Route the Long Cable (23) around the 3 1/2Ó
Pulley (15) and through the Long ÒUÓ-Bracket
(57). Be sure that the Cable is in the
groove of the Pulley and that the Cable
and Pulley move smoothly.
18. Note: The Pulley (15) in this drawing is
pre-assembled. It is shown disassembled
for easy part identification.
Route the Long Cable (23) around the 3 1/2Ó
Pulley (15) attached to the bracket on the Top
Frame (55). Tighten the 3/8Ó x 2Ó Bolt (12)
and the 3/8Ó Nylon Locknut (21). Be sure that
the Cable is in the groove of the Pulley
and that the Cable and Pulley move
smoothly.
18
15
16
17
CABLE ASSEMBLY
48
50
7
6
23
66
15
12
20
68
23
21
12
15
23
57
66
12
15
23
Bracket
55
21
23
