Weider 8510 User Manual

14
26. Attach the Backrest (41) to the Front Upright
(42) with two 1/4Ó x 2 1/2Ó Screws (43) and
two 1/4Ó Flat Washers (10).
27. Press a 1 1/2Ó Square Inner Cap (32) into the
Seat Frame (36).
Insert the 1/4Ó x 2Ó Carriage Bolt (38) into the
center hole in the Seat Plate (37). Attach the
Seat Plate to the Seat (13) with two 1/4Ó x
1/2Ó Screws (18).
Insert the 1/4Ó x 2Ó Carriage Bolt (38) into the
indicated hole in the Seat Frame (36).
Tighten a 1/4Ó Nylon Locknut (2) with a 1/4Ó
Flat Washer (10) onto the Carriage Bolt.
Attach the other end of the Seat (13) to the
Seat Frame (36) with a 1/4Ó Flat Washer (10)
and the 1/4Ó x 2Ó Screw (24).
28. Press a 1 1/2Ó Square Inner Cap (32) into the
Leg Lever (29).
Lubricate the 5/16Ó x 2 1/4Ó Bolt (33). Attach
the Leg Lever (29) to the Seat Frame (36)
with the 5/16Ó x 2 1/4Ó Bolt and a 5/16Ó Nylon
Locknut (3). Do not overtighten the Nylon
Locknut. The Leg Lever must be able to
pivot freely.
Insert the 5/16Ó x 2Ó Eyebolt (35) into the Leg
Lever (29) from the direction shown. Tighten
a 5/16Ó Nylon Locknut (3) with a 5/16Ó Flat
Washer (8) onto the Eyebolt.
26
27
28
SEAT ASSEMBLY
41
42
10
2
24
36
36
3
LubricateÐ33
29
8
3
32
35
2
13
38
37
32
18
10
43

Weider 8510 Specifications

General

Butterfly Station	Yes
Press Arm	Yes
High Pulley	Yes
Low Pulley	Yes
Leg Developer	Yes
Type	Home Gym
Resistance Type	Weight Stack
Weight Capacity	300 lbs.
