Жа,
15.
_
16.
17.
14.
Tap
a
1
3/8"
x
1"
Plastic
Bushing
(149)
into
each
side
of
the
Selector
(3)
(see
the
inset
drawing).
Align
the
Selector
(3)
with
the
Press
Arm
(12)
as
_
shown.
Make
sure
that
the
Press
Arm
is
turned
so.
the
large
holes
are
on
the
side
shown.
Insert
the
10
1/2"
Press
Arm
Tube
(104)
through
the
Press
Arm
and
the
Selector.
Attach
the
Press
Arm
Tube
to
the
Press
Arm
with
two
5/16"
x
2"
Bolts
(95),
two
5/16"
Flat
Washers
(45),
and
two
5/16"
Nylock
Nuts
(4)..
|
Press
a
1"
Round
Outer
Cap
(51)
onto
each
end
of
the
Press
Arm
Tube
(104).
|
|
Press
two
3/4"
Round
Inner
Caps
(36)
into
the
Press
Arm
(12).
Attach
the
Bar
Holder
(58)
to
the
Front
Upright
(19)
with
the
two
1/4"
x
3/4”
Tap
Screws
(89)
and
two
1/4"
Nylock
Nuts
(5).
|
Apply
grease
to
the
Press
Arm
Tube
(104).
Hold
the
Press
Arm
Tube
between
the
two
Press
Arm
Bushings
(60).
Set
the
Press
Arm
Bushings,
the
Press
Arm
Tube,
the
Press
Arm
(12),
and
the
Thin
Metal
Plate
(99)
on
the
Front
Upright
(19).
Place
the
Press
Arm
Cap
(59)
over
the
Press
Arm
:
Bushings.
Attach
the
Press
Arm
Cap
to
the
Front.
А
Upright
with
four
1/4"
x
3/4"
Screws
(7),
four
1/4"
_
Flat
Washers
(6),
and
four
1/4"
Nylock
Nuts
(5).
Extend
the
two
Short
Arm
Shocks
(25).
Apply
a
lib-
eral
amount
of
grease
around
each
Short
Arm
shock
in
the
indicated
location.
Insert
a
Shock
Bar
(26)
into
the
lower
hole
in
the
Pivot
Arm
(75)
as
shown.
Attach
a
Short
Arm
Shock
(25)
to
the
Shock
Bar
with
a
1/4"
x
1
1/4"
Bolt
(66)
and
1/4"
Nylock
Nut(5)—
-
Attach
the
other
Short
Arm
Shock
(25)
to
the
E
Shock
Bar
(26)
in
the
same
manner.
и
|
Г
Press
а
3/4"
Round
Outer
Cap
(65)
onto
each
end
E
of
the
Shock
Bar
(26).
|
x
Pid
