Weider Viper 2000 User Manual

19
A
B
Short Cable (23)
Low Pulley Station
D—Weight Tube
C
Long Cable (66)
High Pulley Station
1
2
3
4
5
7
8—Top Frame
6
CABLE DIAGRAM
The cable diagram below shows the proper routing of the Short Cable (23) and the Long Cable (66). Use the
diagram to make sure that the two cables are assembled correctly. The letters show the routing of the Short
Cable (23); the numbers show the routing of the Long Cable (66).
