Specifications
Technology
Standards
IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X) and 100BaseFX,
IEEE 802.3x for Flow Control
Processing Type
Store and Forward
Flow Control
IEEE 802.3x flow control, back pressure flow
control
Interface
RJ45 Ports
10/100BaseT(X) auto negotiation speed, F/H
duplex mode, and auto MDI/MDI-X connection
Fiber Ports
100BaseFX ports (SC/ST connector,
multi/single-mode)
LED Indicators
P1, P2 (Power), 10/100M (TP port), and 100M
(Fiber port)
DIP Switch
enable/disable broadcast storm protection
Optical Fiber
100BaseFX
Multi-mode
Single-mode
Wavelength
1300 nm
1310 nm
Max. TX
-10 dBm
0 dBm
Min. TX
-20 dBm
-5 dBm
RX Sensitivity
-32 dBm
-34 dBm
Link Budget
12 dB
29 dB
Typical Distance
5 km
a
40 km
c
4 km
b
Saturation
-6 dBm
-3 dBm
a. using [50/125μm, 800 MHz*km] cable
b. using [62.5/125μm, 500 MHz*km] cable
c. using [9/125 μm, 3.5 PS/(nm*km)] cable
Power
Input Voltage
12/24/48 VDC (9.6 to 60 VDC),
18 to 30VAC (47 to 63 Hz)
Input Current
IE-SW-BL05-5TX: 0.1 A @ 24 VDC
IE-SW-BL05-SC/ST/SCS: 0.11 A @ 24 VDC
IE-SW-BL08-8TX: 0.13 A @ 24 VDC
IE-SW-BL08-SC/ST: 0.22 A @ 24 VDC
IE-SW-BL08-SCS: 0.17 A @ 24 VDC
Connection
Removable 4-contact terminal block
Overload Current
Protection
1.1 A
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
IP30 protection, metal case
Dimensions
(W x H x D)
IE-SW-BL05-Models:
30 x 115 x 70 mm (1.18 x 4.52 x 2.76 in)
IE-SW-BL08-Models:
50 x 115 x 70 mm (1.96 x 4.52 x 2.76 in)
Weight
IE-SW-BL05-Models: 175 g
IE-SW-BL08-Models: 275 g
Installation
DIN-Rail Mounting

Weidmüller IE-SW-BL05 Series Specifications

General

Brand	Weidmüller
Model	IE-SW-BL05 Series
Category	Switch
Language	English
