Weigel A1U 2.2 - Short Form Data: Transducers for DC Current;Voltage, RMS Current;Voltage, Isolating Transducers; Short Form Data: Isolating Transducer for Standard Signals, Self-Powered

Short Form Data
Transducers for
DC Current/Voltage,
RMS Current/Voltage,
Isolating Transducers
AUD2.2
VUD 2.2
AUE 2.2
VUE 2.2
TUA 2.2
=
J/U
Inputs
current input voltage input
measuring range 0 ... I
EN
0 ... U
EN
modulation range 1.2 I
EN
1.2 U
EN
overload limit 1.2 I
EN
continuously 1.2 U
EN
continuously
10 I
EN
max. 1 s 2 U
EN
max. 1 s
power consumption ≤ 0.4 VA
model
input quantities rated input value
AUD 2.2 DC current
I
EN
= 200 mA – 5 A
VUD 2.2 DC voltage U
EN
= 60 mV – 600 V
AUE 2.2
nonāĆāsinusoidal AC current
(true RMS value) *)
I
EN
= 200 mA – 5 A
VUE 2.2
nonāĆāsinusoidal AC voltage
(true RMS value) *)
U
EN
= 60 mV – 600 V
TUA 2.2 DC standard signals I
EN
= 20 mA
U
EN
= 60 mV, 10 V
*) also for use on transformer
AUE/VUE 2.2:
frequency range 48 ... 62 Hz or
16
2
/
3
Hz, 100 Hz, other ratings on request
crest factor ≤ 4 (peak value / rms value)
Other Ratings
outputs refer to General Data
as an option selectable from standard output ratings
via jumpers located behind front panel
accuracy class 0.5 (±0.5% of end value)
class 0.2 (±0,2% of end value) only for DC models on request
auxiliary voltage refer to General Data
dimensions WxHxL 22.5 mm x 80 mm x 115 mm
weight approx. 0.12 kg
for detailed information refer to Data Sheet No. 061.##
prices refer to Price Sheet No. 061.##
Short Form Data
Isolating Transducer
for Standard Signals,
Self-Powered
TUP 2.0
=
=
Single or
Dual Channel
Inputs
input quantity I
E
DC current
rated input I
EN
20 mA
current
measuring range 0 ... I
EN
modulation range 1.2 I
EN
overload limit 2 I
EN
max.
continuously
max. input voltage 16 V
permissible
power consumption 2.4 V based on 20 mA
Outputs
current output
output current I
A
load independent DC current
rated current I
AN
0 ... 20 mA
load range R
A
0 ... 500 W (rated load 250 W)
load error ≤ 0.1% based on 50% load change
residual ripple ≤ 30 mV
ss
idling voltage ≤ 25 V
response time ≤ 0.05 s based on R
A max
Input and output are galvanically isolated.
Other Ratings
accuracy class 0.2 (±0.2% of end value)
auxiliary voltage none required
dimensions WxHxL 22.5 mm x 80 mm x 115 mm
weight approx. 0.12 kg
dual channnel unit on request
for detailed information refer to Data Sheet No. 049.##
prices refer to Price Sheet No. 049.##
