11 Technical data
Inhalation flow
at inhalation
outlet in l/min
4±0.8 - -
3 to
15
1 ± 0.30
2 ± 0.40
3 ± 0.45
4 ± 0.60
5 ± 1.00
6 ± 1.20
9 ± 1.80
12 ± 2.40
15 ± 3.00
1 ± 0.30
2 ± 0.40
3 ± 0.45
4 ± 0.60
5 ± 1.00
6 ± 1.20
9 ± 1.80
12 ± 2.40
15 ± 3.00
1 ± 0.30
2 ± 0.40
3 ± 0.45
4 ± 0.60
5 ± 1.00
6 ± 1.20
9 ± 1.80
12 ± 2.40
15 ± 3.00
0.5 ± 0.15
1 ± 0.30
1.5 ± 0.45
2 ± 0.40
2.5 ± 0.50
3 ± 0.60
4 ± 0.80
5 ± 1.00
6 ± 1.20
Throughput at
pressure outlet
in l/min at inlet
pressure 20 bar
-
min.
100
DIN min. 90 AGA min. 90 Bayonet min. 90
- - min. 100
DIN min. 90 AGA min. 90 Bayonet min. 90
-
Throughput at
pressure outlet
in l/min at inlet
pressure
200 bar
-
min.
90
max.
220
DIN min. 150; max.180 AGA min. 150; max. 180 Bayonet min.120, max. q150
--
min. 190
max. 220
DIN min. 150; max.180 AGA min. 150; max. 180 Bayonet min.120, max. q150
-
Opening
pressure of
release valve
7.4 bar
10.4
bar
7.4 bar
Temperature:
Operation
Storage
-20°C to +60°C
-20°C to +70°C
Product class
according to
93/42/EEC
llb
Standards used
EN ISO 10524-1
EN 1789
Designation
OXYWAY Fix I OXYWAY Fix III OXYWAY Fix III, Outlet coupling OXYWAY Fine I OXYWAY Fast I OXYWAY Fast II OXYWAY Fast II, Outlet coupling OXYWAY Fast III
Type
30100 30300 30400 30500 30800 30850 30850 30600
