weinor WGM Top Directions For Use

4
Technische Änderungen vorbehalten | Technische wijzigingen voorbehouden | We reserve the right to make technical changes | Sous réserve de modifications techniques
List of contents
en
General
Please read these instructions and observe their contents and
warnings before using the equipment for the first time!
Intended use
Plaza Viva /LED is a sun protection awning that can primarily be used for
this purpose. Plaza Viva /LED can be used as rain protection contingent on
the instructions for controlled rain drainage. Misuse of the awning, as well
as any alterations, changes or additions to the awning that are carried
out without weinor‘s written permission can lead to damage, hazards or
the collapse of the awning. These are not permitted and will result in the
voiding of the guarantee claims.
Notes on the product:
CE mark / UKCA mark
weinor GmbH & Co. KG declares that the Plaza Viva /LED is in compliance
with the basic requirements and relevant provisions of the EN standards
and UKCA standards. Plaza Viva /LED meets the requirements of the wind
resistance class indicated in the CE conformity marks and UKCA confor
-
mity marks. The requirements shall only be deemed as having been met
once the manufacturer‘s instructions have been adhered to.
Energy eciency class
Plaza Viva LED contains light sources of energy eciency class F.
Noise level
In the non-assembled state, the noise level of this awning is below
70 dB(A).
Note on the generation of noises (creaking) on the system in the
event of temperature changes!
Noises which occur on the system after proper maintenance are unavo-
idable and are mostly due to the expansion of components due to the
eect of heat. Have your system serviced regularly by the specialist com
-
pany! The specialist company checks and maintains the fastening screws
and (if present) the moving bearing points to minimise noise generation,
especially in the case of temperature influences!
Symbols used
Note/Tip
Read instructions,
observe details
„CORRECT“ „INCORRECT“
Power OFF Power ON
Function check/
visual inspection/
check
Action step/
necessary action
en
Safety instructions
Warning! Danger of electric shock due to improper
handling of electric components!
• Follow the installation instructions of the included electric components!
• Work on electrical fixed installation is only permissible when conducted
by electrically skilled persons according to VDE 100!
Careful! Personal injury can result from improper
operation and use of the construction!
• It must be assured that no children or people unable to properly assess the
risks of improper or incorrect use are permitted to operate the awning.
• Always keep the remote radio control out of reach of children!
• Observe the instructions as well as the regulation and operating instruc
-
tions of the manufacturer of the drive, switch or control devices!
• The space needed for the awning to open must always be kept clear. There
is a risk of people being crushed in this space!
• For cleaning, disconnect the power supply (switch o fuses) and switch o
automatic control system when working in the movement range of the
construction in order !
• Do not lean any articles (e.g. gardening devices) against the construction!
• Do not hang any articles (e. g. lamps, leads etc.) on the awning!
Caution! Material damage can result from improper use
and operation of the construction!
• Do not use the construction in case of frost!
• Do not use the construction in strong winds, in order to prevent the dama
-
ge to the awning caused by wind!
• Only use the system as rain protection under supervision and only when
the rain drainage is guaranteed to prevent damage to the system due to
pooling in the fabric.
Water drainage is guaranteed for systems with a pitch of >14° or for
systems with a pitch of >4° and a telescopic post completely lowered on
one side (option). Rain drainage is not guaranteed with over 56 l/h/m2
precipitation (rain class 2)!
• If the awning fabric is retracted while still wet, mould and stains may form!
Only retract a wet awning in the event of an emergency (e.g. with the risk
of a storm, frost or snowfall)! Wet fabric must be dried out as quickly as
possible when the awning is open!
• Adjust the automatic system control to manual operation in your absence
to prevent automatic operation of the construction. The automatic system
control may fail under extreme conditions e.g. power failures, defects or
sudden storms (danger that the awning could be damaged or fall down).
• If there is a risk of frost, rain or storm, the awning system must be switched
from automatic to manual control to prevent it from moving automatically
• Retract the awning in case of frost, rain or portending storm.
• Follow the cleaning instructions in order to prevent damage to the con
-
struction due to erroneous or incomplete cleaning or due tio improper
cleaning agents.
• Adhere to the maintenance instructions/maintenance intervals.
• Only use spare parts which have been approved by the manufacturer!
en
General 4
Safety instructions 4
Use 6
Explanation of wind resistance classes (DIN EN 13561) 6
Operation 7
Lowering / winding up the telescopic post again (option) 8
Operation Volant Plus (Option) 9
Operating instructions to protect against personal injury and damage to property 10
Cleaning 12
Important instructions for cleaning, inspection and maintenance 14
Malfunctions – FAQ 16
Disassembly and Disposal (by a specialist retailer) 18
Product Overview 20
weinor Plaza Viva | Pergola-Markise | Pergola-zonwering | Pergola awning | Store de pergola
120996_GA_PlazaViva_DE-GB-FR-NL_v10_weinor2023-02-21.indd 4120996_GA_PlazaViva_DE-GB-FR-NL_v10_weinor2023-02-21.indd 4 21.02.2023 14:03:5921.02.2023 14:03:59
