weintek M02 - 1.2 Dimensions

M02 Startup Guide
UM021003E_20210505 Copyright© 2021 Weintek Lab., Inc. All rights reserved.
2
1.2 Dimensions
a
SMA Female Connector
b
Male Connector to HMI
Side View
Top View
Side View
54.5mm [2.15"]
80mm [3.15"]
24.1mm [0.95"]
a
54.5mm [2.15"]
80mm [3.15"]
24.1mm [0.95"]
a
54.5mm [2.15"]
80mm [3.15"]
24.1mm [0.95"]
a
b
英文版
簡中版
日文版
上视图
正视图
侧视图侧视图
底视图
上面図
正面図
側面図
背面図
側面図
Antenna 天线
b
b
2000mm [78.74"]
16mm [0.63"]
Foam Sticker
RG174 Black Coaxial Cable
SM A Male Connector
60mm [2.36"]
Wire bending dimension (Min.)
2000mm [78.74"]
16mm [0.63"]
磁性板
RG174 Black Coaxial Cable
SM A Male Connector
60mm [2.36"]
线材绕曲尺寸 (最小)
2000mm [78.74"]
16mm [0.63"]
Foam Sticker
RG174 Black Coaxial Cable
SM A Male Connector
60mm [2.36"]
Wire bending dimension (Min.)
