3.0 Specifications
MT615X MT8150X
Hardware Specification
Display 15.0" TFT
Brightness 350 cd/m
2
Color 65,536 colors
Contrast Ratio 550:1
Resolution (WxH dots) 1024 x 768
Back light CCFLx2
CCFL life time 50,000 hr. min.
Touch panel 4 wires resistive type
Touch Accuracy
Active Area Length(X)±2%, Width(Y)±2%
Surface Hardness
4H
I/O port
COM1 (RS-232/RS-485 2W/4W), COM2(RS232), COM3(RS-232/RS-485 2W)
1 Ethernet port (10/100 Base-T)
Video Input Port
N/A NTSC/PAL RCA x 2 (V2 Only)
USB Host 2 USB Host port
Audio Audio Line Out x 1, MIC In x 1
Processor x86 500MHz processor
Storage 256MB D.O.M
DRAM
256MB on board DDR-400MHz SDRAM
SD card slot Support SD/SDHC
RTC Built-in (CR2032 3V lithium battery.)
General Specification
Input Power 24±10% VDC (21.6~26.4VDC) (Power Isolator Inside)
Power Consumption 1.6 A@24VDC
Isolated Power Supply Built-in
CE/FCC Complies with EN 55022: 1998+A1: 2000+A2: 2003 Class A, EN 61000-3-2: 2000+A2:
2005,EN 61000-3-3: 1995+A1: 2001, EN 55024: 1998+A1: 2001+A2: 2003
Voltage resistance 500VAC (1 min.)
Isolation resistance Exceed 50MΩ at 500VDC 
Vibration endurance 10 to 25 Hz (X,Y,Z direction 2G 30minutes)
Protection structure IP65 front panel (O ring seal)
Storage Temperature -20~60°C (-4° ~ 140°F)
Operating Temperature 0~45°C (32° ~ 113°F)
Operation humidity 10-90% RH (non –condense)
Enclosure Aluminum
Dimensions WxHxD 366 x 293 x 55mm
Panel cutout dimension 352 x 279 mm
Weight Approx. 2.9 kg
Operating System
Operating System Windows CE.net 5.0 EB8000 V4.1.0 or Newer
