36 Part Number STH098 06/19
4. Remove the Water Distribution Tube
• Distribution tube thumbscrews are retained to
prevent loss. Loosen thumbscrews but do not pull
thumbscrews out of distribution tube.
• Loosen the two outer screws and pull forward on
the distribution tube to release.
NOTE: For ease of assembly when reinstalling the water
distribution tube, install the top edge first.
1. LOOSEN THUMBSCREWS
2. PULL DISTRIBUTION TUBE
FORWARD TO REMOVE
