Welch Allyn CP 100 Update To Directions For Use

12 Welch Allyn CP Series Electrocardiographs
Test Directory Usability
• CP 200
More convenient searching
When searching the test directory, you can now enter partial search criteria in the
Patient ID or Last Name fields. For example, to find all patient IDs starting with 12
(including 129374, 12579-125, and 12049-7564), you would enter 12 in the Patient ID
field. To find all patients with last names starting with Jo (including Jones, Johnson,
and Johnston) you would enter Jo in the Last Name field.
Note: Searching is case-insensitive.
• Flexibility in selecting tests from search results
You can now select tests from test directory search results in various ways instead of
all tests being automatically selected.
To select a contiguous group of tests, press and hold Shift while pressing an arrow
key. To select an individual test, press an arrow key. To select all tests, press Ctrl-A.
• Ability to delete saved tests
To delete tests, press the Menu key . Choose Test Directory. Fill in the criteria,
and press Search. In the Search Results screen, choose the tests that you want to
delete. Press the Delete softkey.
External Printer
CP 100, CP 200
You can now connect an external printer. It must be a USB inkjet or laser printer that
supports PCL (printer control language), such as the following:
Printouts are always black and white.
When the external printer is selected in the Device Configuration screen and is powered
on and connected to the electrocardiograph, it prints the following:
• Auto ECG reports
• Spirometry reports (CP 200 spirometry option only)
• Device settings
• Audit trails (CP 200 only)
• Help pages
Rhythm ECGs always print to the internal printer.
To connect a printer, simply connect one end of a USB cable to the printer’s USB
connector, and connect the other end to the electrocardiograph’s USB connector.
No special software is required.
Vendor Model PCL Version
HP Deskjet 995c PCL 3
HP Deskjet 5650 PCL 3 enhanced
HP Laser 1022 PCL 5E
Dell Laser 1710 PCL 5E & PCL 6
Lexmark Laser E240 PCL 6
