46 Chapter 5 Performing ECG Tests Welch Allyn CP 100 Electrocardiograph
Figure 34.“Auto ECG Post-Print” Screen
5. Select the desired item.
Item Effect
Exit The Ready screen appears if all leads are connected to the patient.
Print Copy A copy of the test prints.
To learn how to print multiple copies of all tests automatically, see “Reviewing the
Interpretation and Copy Settings for Auto Reports” on page 36.
Repeat Test The following screen appears.
Figure 35. “Auto ECG Repeat Test” Screen
1. (Optional) Adjust the waveforms.
See “Adjusting the ECG Waveforms” on page 55.
2. Choose Print ECG.
A new report prints.
Export Test Sends the test to the memory card. An SD memory card or removable USB storage device
must be in place.
Doe, Jane
9:17AM Oct 16 05
Auto ECG : Post-Print
1. Exit
2. Print Copy
3. Repeat Test
4. Export Test
Note
Print Copy is not available for Stat Auto ECG, or if
there is no Patient Name or ID entered for Auto
Doe, Jane
9:17AM Oct 16 05
Auto ECG Repeat Test
1. Adjust Gain
2. Adjust Baseline Filter
3. Adjust Muscle Filter
4. Print ECG
10 mm/mV
ON
ON
Note
If you do not enter the patient data, write the patient
identification information on the printed report
immediately after the ECG test to avoid associating the
ECG report with the wrong patient.
