WELDCO MIG145 - Machine Layout

7
MACHINE LAYOUT
1. Positive Terminal
2. Negative Terminal
3. Polarity Cable
INSIDE – WIRE FEED COMPARTMENT
4. Spool Retaining Nut
5. Tension Adjuster
6. Tensioner Arm
7. Roller Retainer Bolt
8. Drive Roller
9. Inlet Guide Tube
10. Spool Brake Tensioner Spring
REAR PANEL
20. ON OFF Switch
21. 10amp 230-volt power cable
22. Shielding Gas Inlet.
1.
3.
4.
10.
8.
9.
5.
6.
2.
7.
20.
21.
22.
INSIDE – WIRE FEED COMPARTMENT
REAR PANEL
