Welker INLOOP ACE - Page 15

3.
Set the actuation time based on process conditions (Table 4 or Table 5).

Table 4: Sample Outlet Pressure and Minimum Actuation Time
Minimum Actuation Time for 1 Stroke Sample Outlet Pressure (psig)
2 Seconds
25
50
100
200
300
400
500
600
700
800
900
1000
3 Seconds
1100
1200
1300
1400
1500

Table 5: Product Viscosity and Minimum Actuation Time
Minimum Actuation Time for 1 Stroke Product Viscosity (cP)
2 Seconds
1
100
200
300
400
600
800
1000
2000
3000
4000
3 Seconds
5000
6000
7000
8000
9000
10,000

15
IOM-224 MODEL: INLOOP™ ACE REV: A 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331
