Wellis Libra - WIRING DIAGRAM - W2000

127
Communication link
(in.touch or in.stik)
Light output (12 V DC)
Power output drivers
Main keypad
connector
Main power entry
connection
Bonding lugs
heat.wav power con-
nection
Probe connectors
(heat.wav's low voltage
cable or regulation probe
and overheat captor
model-re)
Watertight strain
relief system
Pump 1 and
accessory fuse
OVERVIEW
W2000
WIRING DIAGRAM  W2000
