How to Clean (cont.)
06
15
3. After removing the WATER TRAY, remove the TOP COVER & FRONT
COVER by loosening the fixing screws. (Ice-making operation will be
halted.) (Be careful of SCREW loss when opening the product.)
4. Pay attention to the wire while placing the TOP COVER & FRONT
COVER to the side.
5. Connect the drain hoses to the two DRAIN VALVES,(located at the
bottom of the front side), and then proceed to drain completely.
Once completed, remove the drain hoses. (The hot water intake
operation must be performed after cleaning.)
6. Remove the ICE BIN COVER by loosening the fixing screws, and then
disassemble the 2 AUGERS by pulling upward. (During removal &
reassembling, be careful not to lose the CAPS on the AUGERS and
the screws.) (When assembling the auger, pay attention to the
shape of the joint.)
7. Remove the ICE BASKET from the unit
To Next Page
