SPECIFICATIONS
Model Name WS15000
Rated Voltage AC 120 V/60 Hz
Allowable Pressure 14-100 psi (1~7kgf/cm
2
)
Power
Consumption
MAX 4.5 A (505 W)
Weight 71.9 lbs (32.6kg)
Refrigerant/Refrigerant Weight R-134a (1.48 oz ± 0.03 oz)
Design Pressure 280 psig (19.3 bar) (High Side)
Dimensions 360 W x 550D x 450 H (mm) (14.2 W x 21.7 D x 17.7 H (in))
Place of Installation Indoor
Storage
Hot Water 1.25L (42.3oz)
Ice 6.6 lbs (3 kg) (MAX)
Climate Class N Class (32 °C ± 1 °C) (89.6 °F ± 33.8 °C)
Safety Device
Overheating Protector, Water Level Detector,
Water Leakage Shut-Off Valve, Fuse
Power Cord 1.9m (6.3ft) (74.8in)
IP Class IPX1
Room Temp Maximum: 100 °F (37.7 °C), Minimum: 50 °F (10 °C)
Source Water Temp Maximum: 90 °F (32.2 °C), Minimum: 40 °F (4.5 °C)
Relative Humidity 55% at 78 °F (25.5 °C)
