EXPLODED VIEW AND PARTS LIST
No. Part No. Descripon Qty.
1 2307-001 Collet Nut 1
2 2307-002 Brass Collet 1
3 2307-003 Bearing 626zz 1
4 2307-004 Rotor 1
5 2307-005 Bearing 698zz 1
6 2307-006 Stator 1
7 2307-007 Prevent Spring 1
8 2307-008 Spindle Lock Buon 1
9 2307-009 Locking Sleeve 1
10 2307-010 Brush 2
11 2307-011 Brush Spring 2
12 2307-012 Brush Base 2
13 2307-013 Brush Cap 2
14 2307-014 Screw 6
15 2307-015 Right Housing 1
16 2307-016 Circuit Board 1
17 2307-017 Switch 1
18 2307-018 Screw 2
19 2307-019 Place Board 1
20 2307-020 Le Housing 1
21 2307-021 Cord Sleeve 1
22 2307-022 Power Cord 1
