Wen 23190 User Manual

EXPLODED VIEW AND PARTS LIST
No. Part No. Description Quantity
1 23190-001 Collet Nut 1
2 23190-002 Collet 1
3 23190-003 Cap Body 1
4 23190-004 Spindle Lock Button 1
5 23190-005 Gasket 1
6 23190-006 Axis Locking Button 1
7 23190-007 Spring of Spindle Lock 1
8 23190-008 Rotor 1
9 23190-009 Carbon Brush 2
10 23190-010 Screw 6
11 23190-011 Right Body 1
12 23190-012 Stator 1
13 23190-013 Hanger 1
14 23190-014 Panel 1
15 23190-015 Circuit Board 1
16 23190-016 Plug 1
17 23190-017 Cord Sleeve 1
18 23190-018 Switch 1
19 23190-019 Left Body 1
20 23190-020 Right Handle 1
21 23190-021 Left Handle 1
22 23190-022 Screw 2
23 23190-023 Locking Collar 1
13

Wen 23190 Specifications

General

Brand	Wen
Model	23190
Category	Power Tool
Language	English
