EXPLODED VIEW & PARTS LIST
22
No. Part No. Description
100 33013-100 Face Shield
101 33013-101 Clamping Bolt, M6 X 12
102 33013-102 Upper Limiting Bushing, M6
103 33013-103 Upper Limiting Screw, M6 x 16
104 33013-104 Set Screw, M6 X 6
107 33013-107
Handle Seat, Gear
Transmission
108 33013-108 Double Head Bolt, M8 X 70
110 33013-110 Warning Label, Electric Box
111 33013-111 Control Box Cover
112 33013-112 Control Box
113 33013-113 Spindle Gear Shaft
114 33013-114 Key, 4 X 45
116 33013-116 Spacing Ring
118 33013-118 Spacing Ring
119 33013-119 Spindle Nut
120 33013-120 Key, 5 X20
121 33013-121 Cap Screw M5 X 12
122 33013-122 Bearing Cover Plate
123 33013-123 Ball Bearing, 80206
124 33013-124 Name And Specifications Label
125 33013-125 Fine Adjustment Label
126 33013-126 Drawbar Cover
127 33013-127 110 Motor
127A 33013-127-A Key, 3X16
127B 33013-127-B Motor Gear Washer
128 33013-128 Motor Gear 14T
129 33013-129 C-Clip, Ø9.0
130 33013-130 Motor Seat Plate
131 33013-131 Flat Screw, M6 X 12
132 33013-132 Round Screw M5 X 8
133 33013-133 Yellow LED
134 33013-134
Speed Control Knob With
Potentiometer
135 33013-135 Green LED
136 33013-136 Fuse Cap
136-1 33013-136-1 Fuse, 5A
137 33013-137 Emergency Stop Switch
138 33013-138 Gear, 30T
139 33013-139 Ball Bearing, 80101
140 33013-140
Transmission Compound Gear,
20/12T
141 33013-141 Clutch Fork
142 33013-142 Clutch Plate
143 33013-143 Set Screw, M5 X 8
No. Part No. Description
144 33013-144 Self-Tapping Screw, St2.9 X 8
145 33013-145 High/Low Label
146 33013-146 Motor Cover
149 33013-149 Warning Label, Drawbar Cover
150 33013-150 PCB
151 33013-151 Lock Sleeve
152 33013-152 Pivot Shaft
153 33013-153 Key 4 X 6
154 33013-154 Spring Support Bushing
155 33013-155 Torsion Spring
156 33013-156 Spring Cover
157 33013-157 Acorn Nut, M8
158 33013-158 Pivot Bar
159 33013-159 Slotted Support Bar
160 33013-160 Screw
161 33013-161 Bushing
162 33013-162 Washer, M12
163 33013-163 Support Bar Cover
164 33013-164 Column Cover
200 33013-200 Z-Axis Ruler Base Flange
201 33013-201 Screw, M3 X 8
202 33013-202 Rivet, M2 X 3
203 33013-203 Screw, M5 X 6
204 33013-204 Screw, M5 X 8
205 33013-205 Screw, M5 X 8
206 33013-206 Washer, M5
207 33013-207 Screw, M6 X 8
208 33013-208 Fixed Sleeve
209 33013-209 Washer
210 33013-210 Drawbar, M12-1.75
211 33013-211 Collet, R8
212 33013-212 Chuck, JT33, 1 – 13mm
213 33013-213 Box Wrench, 36mm
214 33013-214 Spindle Locking Rod
215 33013-215 Hook Wrench, D45-52
216 33013-216 Combi Box Wrench, 19/17mm
217 33013-217 Combi Box Wrench, 17/14mm
218 33013-218 Combi Box Wrench, 10/8mm
219 33013-219 Chuck Key
220 33013-220 Extra Fuse, 5A
221 33013-221 T-Nut
222 33013-222 Oil Bottle
223 33013-223
Hex Wrench Set (M6 M5 M4
M3)
224 33013-224 Carbon Brushes Set
NOTE: Repairs and replacements should only be performed by an authorized technician. Parts and accessories
that wear down over the course of normal use are not covered by the two-year warranty.
