KNOW YOUR LATHE
TOOL PURPOSE
Turn pens, chess pieces, cups, and more with your WEN Woodworking Lathe. Refer to the following diagrams to
become familiarized with all the parts and controls of your lathe. The components will be referred to later in the
manual for assembly and operation instructions.
Headstock
Power Switch
Variable Speed
Faceplate
Tool Rest Lock
Motor
Tool Rest
Live Center
Quill Lock
Tailstock
Handwheel
Tailstock
Tailstock Lock
WOODWORKING LATHE
BENCHTOP MOUNTING GUIDE
1
2
23 3/8" (59.4 cm)
2 1/2"
(6.4 cm)
4 1/8"
(10.5 cm)
2 1/16"
(5.2 cm)
7/16"
(1.1 cm)
22 1/2"
(57.2 cm)
7/16"
(1.1 cm)
5 1/4"
(13.3 cm)
8
