EXPLODED VIEW AND PARTS LIST
No. Part Number Part Description Qty
1 4017-001 Oil Tank Cap Assembly 1
1-1 4017-002 Cap Cover 1
1-2 4017-003 Oil Tank Cap 1
1-3 4017-004 Seal Ring 1
1-4 4017-005 Hanger 1
2 4017-006 The Oil Tank Opening Sealing Ring 1
3 4017-007 Oil Tank Assembly 1
3-1 4017-008 Valve 1
3-2 4017-009 Oil Tank 1
3-3 4017-010 Oil Box Joint Core Plug 1
3-4 4017-011 Sponge 1
3-5 4017-012 Oil Tank Delivery Connection 1
3-6 4017-013 Oil Tank Joint Rubber Sleeve 1
3-7 4017-014 Transparent Oil Hosing 1
4 4017-015 Power Line 1
5 4017-016 Cable Sheath 1
6 4017-017 Power Cable Screws 2
7 4017-018 Cable Clamp 1
8 4017-019 Connector 2
9 4017-020 Copper Strip 1
10 4017-021 Connecting Wire 1
11 4017-022 Connecting Wire 1
12 4017-023 Switch Spring 1
13 4017-024 Switch Button 1
14 4017-025 Anti Lock Button Spring 1
15 4017-026 Lock Button 1
16 4017-027 Plug Screw 1
17 4017-028 Microswitch 1
18 4017-029 Connecting Wire 1
19 4017-030 Hexagon Nut With Flange 1
20 4017-031 Motor Gear 1
21 4017-032 Motor Gear Bushing 1
22 4017-033 Motor Plate Screws 11
23 4017-034 Left Housing 1
24 4017-035 Rotor Subassembly 1
24-1 4017-036 Bearing 1
24-2 4017-037 Rotor 1
24-3 4017-038 Bearing 1
25 4017-039 Washer 1
26 4017-040 Stator Subassembly 1
26-1 4017-041 Stator Screw 2
26-2 4017-042 Spring Washer 2
26-3 4017-043 Flat Gasket 2
26-4 4017-044 Front Stator Housing 1
26-5 4017-045 Stator 1
26-6 4017-046 Motor Back 1
26-7 4017-047 Brush Mount 2
26-8 4017-048 Washer 2
No. Part Number Part Description Qty
26-9 4017-048 Hexagon Nut 2
27 4017-049 Brush 2
28 4017-050 Brush Cover 2
29 4017-051 Brush Cover Screws 4
30 4017-052 Motor Housing 1
31 4017-053 Brake Handle Screw 2
32 4017-054 Brake Washer 1
33 4017-055 Brake Handle 1
34 4017-056 Oil Pump Subassembly 1
34-1 4017-057 Worm Gear End 1
34-2 4017-058 Worm Gear 1
34-3 4017-059 Oil Pump 1
34-4 4017-060 Oil Pump Screws 1
35 4017-061 Transparent Oil Hosing 1
36 4017-062 Oil Nozzle 1
37 4017-063 Oring 2
38 4017-064 Output Shaft Subassembly 1
38-1 4017-065 Hex Lock Nut 1
38-2 4017-066 608Z Bearing 1
38-3 4017-067 Output Shaft Gear 1
38-4 4017-068 Output Shaft 1
38-5 4017-069 6900 Bearing 1
39 4017-070 Dust Shield 1
40 4017-071 Right Housing Sub Assembly 1
40-1 4017-072 Right Housing Plug 1
40-2 4017-073 Bumper Screws 2
40-3 4017-074 Clamp 1
40-4 4017-075 M8 Stud 1
40-5 4017-076 Right Housing 1
40-6 4017-077 Blade Adjustment Assembly 1
40-7 4017-078 Blade Adjustment Wheel 1
40-8 4017-079 Bumper 1
40-9 4017-080 Countersunk Bumper Screws 2
40-10 4017-081 Oil-Out Seal Ring 1
41 4017-082 Tensioning Spring 1
42 4017-083 Sprocket 1
43 4017-084 Chain Gear Baffle 1
44 4017-085 Clip 1
45 4017-086 Main Housing Screws 11
46 4017-087 Recessed Housing Screws 1
47 4017-088 Chain 1
48 4017-089 Bar 1
49 4017-090 Blade Adjustment Cover Assembly 1
49-1 4017-091 Knob 1
49-2 4017-092 Spindle 1
49-3 4017-093 Adjustment Cover 1
49-4 4017-094 End Cap Seal Ring 1
50 4017-095 Blade Cover 1
