EXPLODED VIEW & PARTS LIST
16
No. Part No. Description Qty.
1 41121-001 Hopper 1
2 41121-002 Preventer Plate 1
3 41121-003 Press Bar 1
4 41121-004 Self Tapping Screw 15
5 41121-005 Handle 1
6 41121-006 Flange Tapping Screw 17
7 41121-007 Housing 1
8 41121-008 Hopper Locking Knob 1
9 41121-009 Compression Spring 1
10 41121-010 Knob Holder 1
11 41121-011 Washer 1
12 41121-012 Switch Pin 1
13 41121-013 Washer 1
14 41121-014 Axis With Circlips 1
15 41121-015
Type 1 Non-Metallic
Hex Nuts
2
16 41121-016 Pull Rod 1
17 41121-017 Air Deflector 1
18 41121-018 Dust Against Plate 1
19 41121-019 Self Tapping Screw 8
20 41121-020 Hexagon Headed Bolt 1
21 41121-021 Internal Washer 1
22 41121-022 Briquet 1
23 41121-023 Hexagon Screw 4
24 41121B Blade 2
25 41121-025 Static Blade 1
26 41121-026 Transmission Shaft 1
27 41121-027 Motor Assembly 1
27-1 41121-027-1 Tapping Screw 19
27-2 41121-027-2
Reduction Casing Upper
Cover
1
27-3 41121-027-3 Belt 1
27-4 41121-027-4 Belt-Wheel 1 1
27-5 41121-027-5 Belt-Wheel 2 1
27-6 41121-027-6 Wobbler 1
27-7 41121-027-7
Reduction Casing
Lower Cover
1
27-8 41121-027-8 Spring Washer 2
27-9 41121-027-9 Flat Washer 4
27-10 41121-027-10 Stator Screw 2
27-11 41121-027-11 Motor Front Bracket 1
27-12 41121-027-12 Stator Assembly 1
No. Part No. Description Qty.
27-13 41121-027-13 Rotor Assembly 1
27-14 41121-027-14 627 Bearing 1
27-15 41121-027-15 Motor Rear Bracket 1
27-16 41121-027-16 Tapping Screw 4
27-17 41121-027-17
Carbon Brush
Assembly
2
27-18 41121-027-18 2
24-19 41121-027-19 Hexagon Nut 2
27-20 41121-027-20 Plate For Brush Holder 2
28 41121-028 Plastic Pin 2
29 41121-029 Base 1
30 41121-030 Strong Off Switch 1
31 41121-031 Hexagon Nut 1
32 41121-032 Safety Key 1
33 41121-033
Electrical Assembly
Components
1
34 41121-034 Cable Clamp 1
35 41121-035 Sleeve Clamp 1
36 41121-036 Housing Assembly 1
37 41121-037 Overload Protector 1
38 41121-038 Dustproof Power Switch 1
39 41121-039 Cable Sleeve 1
40 41121-040 Power Cord 1
41 41121-041 Screw 2
42 41121-042
Carbon Brush
Front Cover
1
43 41121-043 Push Stick 1
44 41121-044
Carbon Brush
Rear Cover
1
45 41121-045 Fixing Holder 1
46 41121-046 Lower Frame 1
47 41121-047 Axle 1
48 41121-048 Wheel 2
49 41121-049 Lock Nut 2
50 41121-050 Wheel Cover 2
51 41121-051 Connecting Wire 2
52 41121-052 Connecting Wire 1
53 41121-053 Collection Bag 1
54 41121-054 Heat Shrinkable Tube 1
55 41121-055 Heat Shrinkable Tube 1
56 41121-056 Nylon Rope 2
57 41121-057 Wrench 1
58 41121-058 Hex Wrench 1
