Wen 4212T User Manual

25
No. Part No. Description Qty.
1 4212B-001 Retaining plate 1
2 4212B-002 Set screw, M8x12 1
3 4212B-003 Cam 1
4 4212B-004 Ball bearing, 6907Z 1
5 4212B-005 Elastic ring 1
6 4212B-006
Spindle movable pul-
ley
1
7 4212B-007 Spindle fixed pulley 1
8 4212B-008 Key, A type, 4x4x64 1
9 4212B-009 Shaft sleeve 1
10 4212B-010 Ball bearing, 6203RZ 2
11 4212B-011 Retainer 1
12 4212B-012 Circlip, Ø17 1
13 4212B-013 V-belt, Z-800 1
14 4212B-014 Circlip, Ø14 1
15 4212B-015 Motor fixed pulley 1
16 4212B-016 Motor movable pulley 1
17 4212B-017 Hex screw, M8x12 6
18 4212B-018
Motor compression
spring
1
19 4212B-019 Key, A type, 4x4x84 1
20 4212B-020 Spring base 1
21 4212B-021 Spring washer 1
22 4212B-022 Screw, M5x12 6
23 4212B-023 Cord clamp 3
24 4212B-024 Screw, M6x12 5
25 4212B-025 Pulley cover assembly 1
26 4212B-026 Rubber bushing 2
27 4212B-027 Handle knob 4
28 4212B-028 Handle shaft 3
29 4212B-029 Chuck key holder 1
30 4212B-030 Spring pin, 6-15 2
31 4212B-031 Hex screw, M8x8 2
32 4212B-032 Speed sensor 1
33 4212B-033 Speed sensor base 1
34 4212B-034 Screw, M5x6 1
35 4212B-035 Screw, ST2.9x6 2
36 4212B-036 Laser switch 1
37 4212B-037 Battery housing cover 1
No. Part No. Description Qty.
38 4212B-038 Battery housing 1
39 4212B-039 Handle seat 1
40 4212B-040 Spring pin, 5-15 2
41 4212B-041 Feed shaft 1
42 4212B-042 Depth locking knob 1
43 4212B-043 Scale collar 1
44 4212B-044 Screw, M6x12 1
45 4214B-029-01 Digital readout display 1
46 4212B-046 Switch box 1
47 4212B-047 Switch plate 1
48 4212B-048 Screw, ST4.9x16 2
49 4212B-049 Terminal 6
50 4212B-050 Screw, ST4.2x10 2
51 4212B-051 ON/OFF switch 1
52 4212B-052 Flange screw, M5x12 1
53 4212B-053 Screw, M5x8 2
54 4212B-054 Toothed washer, 5mm 2
55 4212B-055 Spindle circlip 1
56 4212B-056 Ball bearing, 6201Z 2
57 4212B-057 Rubber washer, 40mm 1
58 4212B-058 Quill 1
59 4212B-059 Spindle, JT33 1
60 4212B-060 Chuck, JT33 1
61 4212B-061 Chuck key 1
62 4212B-062 Rack shaft 1
63 4212B-063 Rack shaft spring 1
64 4212B-064 Washer, 8mm 1
65 4212B-065 Hex flange bolt 5
66 4212B-066 Laser 2
67 4212B-067 Collar 1
68 4212B-068 Internal gear 1
69 4212B-069 Worm gear 1
70 4212B-070 Table support 1
71 4212B-071 Crank handle 1
72 4212B-072 Inner gear shaft 1
73 4212B-073 Table lock handle 1
75 4212B-075 Table 1
76 4212B-076 Hex bolt, M12x25 1
77 4212B-077 Rack 1
EXPLODED VIEW & PARTS LIST
